Intel CD8068904657901-RFB Xeon SL 4310 Proc 18M CD8068904657901-RFB

Intel® Turbo Boost Technology

Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Intel® Hyper-Threading Technology

Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel® Virtualization Technology (VT-x)

Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® Virtualization Technology for Directed I/O (VT-d)

Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® VT-x with Extended Page Tables (EPT)

Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel® 64

Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Instruction Set

An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel’s instruction set this processor is compatible with.

Instruction Set Extensions

Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

# of AVX-512 FMA Units

Intel® Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.

Intel® Speed Shift Technology

Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Deep Learning Boost (Intel® DL Boost)

A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Resource Director Technology (Intel® RDT)

Intel® RDT brings new levels of visibility and control over how shared resources such as last-level cache (LLC) and memory bandwidth are used by applications, virtual machines (VMs) and containers.

Intel® Volume Management Device (VMD)

Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Features



Commodity Classification Automated Tracking System (CCATS)



G178966


Embedded options available



Yes


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



5A992CN3


Market segment



Server


Maximum number of PCI Express lanes



64


PCI Express slots version



4.0


Scalability



2S


Supported instruction sets



SSE4.2, AVX, AVX 2.0, AVX-512


Graphics



Discrete graphics card



No


Discrete graphics card model



Not available


On-board graphics card



No


On-board graphics card model



Not available


Logistics data



Harmonized System (HS) code



85423119


Memory



ECC



Yes


Maximum internal memory supported by processor



6 TB


Memory channels



Octa-channel


Memory clock speeds supported by processor



2667


Memory types supported by processor



DDR4-SDRAM


Operational conditions



Tcase



82 °C


Other features



Maximum internal memory



6 TB


Package dimensions



Depth (package,cm)



5 cm


Gross Weight (Package, kg)



0.3 kg


Height (package,cm)



0.5 cm


Width (package,cm)



5 cm


Processor



Box



No


Component for



Server/workstation


Cooler included



No


Processor ARK ID



215277


Processor base frequency



2.1 GHz


Processor boost frequency



3.3 GHz


Processor cache



18 MB


Processor codename



Ice Lake


Processor cores



12


Processor family



Intel Xeon Silver


Processor generation



3rd Generation Intel® Xeon® Scalable


Processor lithography



10 nm


Processor manufacturer



Intel


Processor model



4310


Processor operating modes



64-bit


Processor socket



LGA 4189


Processor threads



24


System bus rate



10.4 GT/s


Thermal Design Power (TDP)



120 Watt


Processor special features



AVX-512 Fused Multiply-Add (FMA) units



2


Intel 64



Yes


Intel Software Guard Extensions (Intel SGX)



Yes


Intel Trusted Execution Technology



Yes


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel® AES New Instructions (Intel® AES-NI)



Yes


Intel® Crypto Acceleration



Yes


Intel® Deep Learning Boost (Intel® DL Boost)



Yes


Intel® Hyper Threading Technology (Intel® HT Technology)



Yes


Intel® Optane™ DC Persistent Memory Supported



No


Intel® Platform Firmware Resilience Support



Yes


Intel® Speed Shift Technology



Yes


Intel® Total Memory Encryption



Yes


Intel® Transactional Synchronization Extensions



Yes


Intel® Turbo Boost Technology



2.0


Intel® Volume Management Device (VMD)



Yes


Maximum Enclave Size Support for Intel® SGX



8 GB


Product dimensions



Net Weight (Product, kg)



0.137 kg


Technical details



Launch date



Q2'21


Memory speed (max)



2667 MHz


Number of UPI links



2


Servicing status



Baseline Servicing


Status



Launched


Supported memory types



DDR4-SDRAM


Target market



Cloud Computing


Vendor information



Brand Name


Intel


Warranty



1 Year(s)


Weight & dimensions



Processor package size



77.5 x 56.5 mm
