Intel CM8063701137502-RFB Core i3-3220 3300MHz 3M TRAY CM8063701137502-RFB

Intel� Hyper-Threading Technology
Intel� Hyper-Threading Technology (Intel� HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel� My WiFi Technology
Intel� My WiFi Technology enables wireless connection of an UltrabookTM or laptop to WiFi-enabled devices such as printers, stereos, etc.

Intel� Identity Protection Technology
Intel� Identity Protection Technology is a built-in security token technology that helps provide a simple, tamper-resistant method for protecting access to your online customer and business data from threats and fraud. Intel� IPT provides a hardware-based proof of a unique user�s PC to websites, financial institutions, and network services; providing verification that it is not malware attempting to login. Intel� IPT can be a key component in two-factor authentication solutions to protect your information at websites and business log-ins.

Anti-Theft Technology
Intel� Anti-Theft Technology (Intel� AT) helps keep your laptop safe and secure in the event that it�s ever lost or stolen. Intel� AT requires a service subscription from an Intel� AT�enabled service provider.

Features



Commodity Classification Automated Tracking System (CCATS)



NA


CPU configuration (max)



1


Embedded options available



Yes


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



3A991


Idle States



Yes


Market segment



Desktop


PCI Express CEM revision



2.0


PCI Express configurations



1x16, 2x8, 1x8, 2x4


PCI Express slots version



2.0


Supported instruction sets



SSE4.1, SSE4.2, AVX


Thermal Monitoring Technologies



Yes


Thermal solution specification



PCG 2011C


Graphics



Number of displays supported (on-board graphics)



3


On-board graphics card



Yes


On-board graphics card base frequency



650 MHz


On-board graphics card dynamic frequency (max)



1050 MHz


On-board graphics card model



Intel� HD Graphics 2500


Logistics data



Harmonized System (HS) code



8542310001


Memory



ECC



No


Maximum internal memory supported by processor



32 GB


Memory channels



Dual-channel


Memory clock speeds supported by processor



1333, 1600


Memory types supported by processor



DDR3-SDRAM


Operational conditions



Tcase



65.3 �C


Other features



Maximum internal memory



32768 MB


Maximum internal memory



32 GB


Package dimensions



Gross Weight (Package, kg)



0.2 kg


Processor



Box



No


Bus type



DMI


Component for



PC


Cooler included



No


CPU multiplier (bus/core ratio)



33


Generation



3rd Generation


Memory bandwidth supported by processor (max)



25.6 GB/s


Processor ARK ID



65693


Processor base frequency



3.3 GHz


Processor cache



3 MB


Processor cache type



Smart Cache


Processor codename



Ivy Bridge


Processor cores



2


Processor family



Intel� Core� i3


Processor generation



3rd gen Intel� Core� i3


Processor lithography



22 nm


Processor manufacturer



Intel


Processor model



i3-3220


Processor operating modes



64-bit


Processor series



Intel Core i3-3200 Desktop Series


Processor socket



LGA 1155 (Socket H2)


Processor threads



4


System bus rate



5 GT/s


Thermal Design Power (TDP)



55 Watt


Processor special features



Conflict-Free processor



Yes


Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Enhanced Halt State



Yes


Intel FDI Technology



Yes


Intel Identity Protection Technology version



1.00


Intel Secure Key Technology version



0.00


Intel Trusted Execution Technology



No


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



No


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel� AES New Instructions (Intel� AES-NI)



No


Intel� Anti-Theft Technology (Intel� AT)



Yes


Intel� Clear Video HD Technology (Intel� CVT HD)



Yes


Intel� Hyper Threading Technology (Intel� HT Technology)



Yes


Intel� Identity Protection Technology (Intel� IPT)



Yes


Intel� Insider�



Yes


Intel� InTru� 3D Technology



Yes


Intel� My WiFi Technology (Intel� MWT)



Yes


Intel� Quick Sync Video Technology



Yes


Intel� Secure Key



No


Intel� Turbo Boost Technology



No


Intel� vPro� Platform Eligibility



No


Intel� Wireless Display (Intel� WiDi)



Yes


Product dimensions



Net Weight (Product, kg)



0.1 kg


Technical details



Bus bandwidth



5


Bus speed



5 GT/s


Bus type units



GT/s


Last change



63903513


Launch date



Q3'12


Maximum memory



32 GB


Processor brand name



Intel Core i3 Intel Core i3 Processor


Processor cache



3072 KB


Processor ID



0x152


Product family



3rd Generation Intel Core i3 Processors


Product type



Processor


Status



Discontinued


Supported memory types



DDR3-SDRAM


Vendor information



Brand Name


Intel


Warranty



1 Year(s)


Weight & dimensions



Processor package size



37.5 x 37.5 mm
