Intel CM8066201920103 Core i7-6700. Quad Core. CM8066201920103

The 6th generation Intel� Core� i7 processors deliver a new class of computing with a host of new features to power the next generation of laptops and 2 in 1 PCs. Expect lighting fast speeds and peak performance through even the toughest of tasks and games. The built-in revolutionary Intel� Hyper-Threading Technology allows each processor core to work on two tasks at the same time for smoother multitasking while Intel� Iris� graphics delivers stunning 3D visuals and faster, more advanced video and photo editing. Game the way you want and push the boundaries with overclocking for your most demanding gaming needs. The ultimate in peak performance.

Ready. Wake. Create.
From zero to power in a flash, the 6th generation Intel� Core� processor wakes quicker than ever and lets you switch in and out of apps more seamlessly than ever.

Stunning Visual Experiences
With 6th generation Intel� Core� processor Ultra HD graphics, your screen comes to life. Watch in a whole new way with 4k screens. Wireless displays let you create and game anywhere.

Security You Can Trust
Worry-free and hassle-free security is yours. With facial recognition and True Key� technology, getting you logged in and protected has never been easier or more secure.

Features



Commodity Classification Automated Tracking System (CCATS)



G077159


CPU configuration (max)



1


Embedded options available



Yes


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



5A992C


Graphics & IMC lithography



14 nm


Idle States



Yes


Market segment



Desktop


Maximum number of PCI Express lanes



16


PCI Express CEM revision



3.0


PCI Express configurations



1x16, 2x8, 1x8+2x4


PCI Express slots version



3.0


Scalability



1S


Supported instruction sets



SSE4.1, SSE4.2, AVX 2.0


Thermal Monitoring Technologies



Yes


Thermal solution specification



PCG 2015C


Graphics



Maximum on-board graphics card memory



64 GB


Number of displays supported (on-board graphics)



3


On-board graphics card



Yes


On-board graphics card 4K support



Yes


On-board graphics card base frequency



350 MHz


On-board graphics card DirectX version



12.0


On-board graphics card dynamic frequency (max)



1150 MHz


On-board graphics card maximum resolution (DisplayPort)



4096 x 2304 Pixels


On-board graphics card maximum resolution (eDP - Integrated Flat Panel)



4096 x 2304 Pixels


On-board graphics card maximum resolution (HDMI)



4096 x 2304 Pixels


On-board graphics card model



Intel� HD Graphics 530


On-board graphics card OpenGL version



4.5


On-board graphics card outputs supported



Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI


On-board graphics card refresh rate at maximum resolution (DisplayPort)



60 Hz


On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)



60 Hz


On-board graphics card refresh rate at maximum resolution (HDMI)



24 Hz


Logistics data



Harmonized System (HS) code



85423119


Memory



ECC



No


Maximum internal memory supported by processor



64 GB


Memory channels



Dual-channel


Memory clock speeds supported by processor



1333, 1600, 1866, 2133


Memory types supported by processor



DDR4-SDRAM, DDR3L-SDRAM


Memory voltage supported by processor



1.35 V


Operational conditions



Tcase



71 �C


Other features



Graphics output



eDP/DP/HDMI/DVI


Maximum internal memory



65536 MB


Maximum internal memory



64 GB


Video decoding



Yes


Package dimensions



Gross Weight (Package, kg)



1.2 kg


Processor



Box



No


Bus type



DMI3


Compatible chipsets



Intel� B150, Intel� H110, Intel� H170, Intel Q150, Intel� Q170, Intel� Z170


Component for



PC


Cooler included



No


Generation



6th Generation


Memory bandwidth supported by processor (max)



34.1 GB/s


Processor ARK ID



88196


Processor base frequency



3.4 GHz


Processor boost frequency



4 GHz


Processor cache



8 MB


Processor cache type



Smart Cache


Processor code



SR2L2


Processor codename



Skylake


Processor cores



4


Processor family



Intel� Core� i7


Processor generation



6th gen Intel� Core� i7


Processor lithography



14 nm


Processor manufacturer



Intel


Processor model



i7-6700


Processor operating modes



64-bit


Processor series



Intel Core i7-6700 Desktop series


Processor socket



LGA 1151 (Socket H4)


Processor threads



8


Stepping



R0


System bus rate



8 GT/s


Thermal Design Power (TDP)



65 Watt


Processor special features



Conflict-Free processor



Yes


Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Clear Video Technology



Yes


Intel Enhanced Halt State



Yes


Intel Identity Protection Technology version



1.00


Intel Secure Key Technology version



1.00


Intel Small Business Advantage (SBA) version



1.00


Intel Software Guard Extensions (Intel SGX)



Yes


Intel Stable Image Platform Program (SIPP)



Yes


Intel Stable Image Platform Program (SIPP) version



1


Intel Trusted Execution Technology



Yes


Intel TSX-NI



Yes


Intel TSX-NI version



1.00


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel� AES New Instructions (Intel� AES-NI)



Yes


Intel� Boot Guard



Yes


Intel� Clear Video HD Technology (Intel� CVT HD)



Yes


Intel� Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)



Yes


Intel� Hyper Threading Technology (Intel� HT Technology)



Yes


Intel� Identity Protection Technology (Intel� IPT)



Yes


Intel� Insider�



Yes


Intel� InTru� 3D Technology



Yes


Intel� Memory Protection Extensions (Intel� MPX)



Yes


Intel� Optane� Memory Ready



No


Intel� OS Guard



Yes


Intel� Quick Sync Video Technology



Yes


Intel� Secure Key



Yes


Intel� Small Business Advantage (Intel� SBA)



Yes


Intel� Transactional Synchronization Extensions



Yes


Intel� Turbo Boost Technology



2.0


Intel� Turbo Boost Technology 2.0 frequency



4 GHz


Intel� vPro� Platform Eligibility



Yes


Intel� Wireless Display (Intel� WiDi)



Yes


Product dimensions



Net Weight (Product, kg)



1 kg


Technical details



Bus bandwidth



8


Bus speed



8 GT/s


Bus type units



GT/s


End of servicing updates date



Friday, September 30, 2022


Last change



63903513


Launch date



Q3'15


Maximum graphics card memory



64 GB


Maximum memory



64 GB


Maximum resolution & refresh rate (DisplayPort)



4096x2304@60Hz


Maximum resolution & refresh rate (HDMI)



4096x2304@24Hz


Maximum resolution & refresh rate (Integrated Flat Panel)



4096x2304@60Hz


Maximum resolution & refresh rate (VGA)



N/A


Maximum resolution (WiDi)



1080p


Number of graphics cores



2


Processor brand name



Intel Core i7 Intel Core i7 Processor


Processor cache



8192 KB


Processor ID



0x1912


Product family



6th Generation Intel Core i7 Processors


Product type



Processor


Servicing status



End of Servicing Lifetime


Status



Launched


Supported memory types



DDR4-SDRAM, DDR3L-SDRAM


Vendor information



Brand Name


Intel


Warranty



3 Month(s)


Weight & dimensions



Processor package size



37.5 x 37.5 mm
