Intel CM8067702867064-RFB Pentium G4560 processor 3.5 CM8067702867064-RFB

Exceptional Performance for Work, Play, and Beyond
Prime yourself for more of everything you want and need. The latest Intel� Pentium� processors let you stream, share, shop, play, create, and consume�all at the same time.

Discover a new dimension in productivity with Intel�s next-generation Pentium� processors. Performance optimized to accelerate portable 2 in 1s, laptops, towers, desktops, and All-in-Ones. Go thinner, sleeker, and smaller with reliability you can count on.

Featuring Splendid Audiovisuals
Whether you are streaming Ultra HD video to a big screen or simply reading the news, get impressive multimedia and entertainment features in a wide range of devices with the latest Intel� Pentium� processors.

Chat, Shop, or Surf in Style
Get exceptional computing performance to keep your life moving. Browse the web, shop, and communicate with friends simultaneously. With improved graphics, light weight and low-power consumption, witness a processor built for better experiences.

Whatever You Do, Do It Faster
The new Intel� Pentium� processor has improved functionality for multitasking, helping you get more work done with less stress. Create, edit, and organize critical documents while managing photos and staying on top of emails.

Never Stop Playing
The Intel� Pentium� features upgraded graphics and computing performance to juice up your casual gaming life. Level up your enjoyment with more seamless action and snappier gameplay experiences.

Features



Commodity Classification Automated Tracking System (CCATS)



G077159


CPU configuration (max)



1


Embedded options available



No


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



5A992C


Graphics & IMC lithography



14 nm


Idle States



Yes


Market segment



Desktop


Maximum number of PCI Express lanes



16


PCI Express CEM revision



3.0


PCI Express configurations



1x16, 2x8, 1x8+2x4


PCI Express slots version



3.0


Scalability



1S


Supported instruction sets



SSE4.1, SSE4.2


Thermal Monitoring Technologies



Yes


Thermal solution specification



PCG 2015C


Graphics



Maximum on-board graphics card memory



64 GB


Number of displays supported (on-board graphics)



3


On-board graphics card



Yes


On-board graphics card 4K support



Yes


On-board graphics card base frequency



350 MHz


On-board graphics card DirectX version



12.0


On-board graphics card dynamic frequency (max)



1050 MHz


On-board graphics card maximum resolution (DisplayPort)



4096 x 2304 Pixels


On-board graphics card maximum resolution (eDP - Integrated Flat Panel)



4096 x 2304 Pixels


On-board graphics card maximum resolution (HDMI)



4096 x 2304 Pixels


On-board graphics card model



Intel� HD Graphics 610


On-board graphics card OpenGL version



4.4


On-board graphics card outputs supported



DisplayPort, Embedded DisplayPort (eDP), HDMI


On-board graphics card refresh rate at maximum resolution (DisplayPort)



60 Hz


On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)



60 Hz


On-board graphics card refresh rate at maximum resolution (HDMI)



24 Hz


Logistics data



Harmonized System (HS) code



8542310001


Memory



ECC



Yes


Maximum internal memory supported by processor



64 GB


Memory channels



Dual-channel


Memory clock speeds supported by processor



1333, 1600, 2133, 2400


Memory types supported by processor



DDR4-SDRAM, DDR3L-SDRAM


Memory voltage supported by processor



1.35 V


Operational conditions



Tjunction



100 �C


Other features



Maximum internal memory



65536 MB


Maximum internal memory



64 GB


Video decoding



Yes


Package dimensions



Depth (package,cm)



11.6 cm


Gross Weight (Package, kg)



0.337 kg


Height (package,cm)



10.1 cm


Width (package,cm)



7 cm


Processor



Box



No


Bus type



DMI3


Component for



PC


Cooler included



No


Processor ARK ID



97143


Processor base frequency



3.5 GHz


Processor cache



3 MB


Processor code



SSSSR32Y


Processor codename



Kaby Lake


Processor cores



2


Processor family



Intel Pentium G


Processor lithography



14 nm


Processor manufacturer



Intel


Processor model



G4560


Processor operating modes



64-bit


Processor series



Intel Pentium G4500 Series For Desktop


Processor socket



LGA 1151 (Socket H4)


Processor threads



4


Stepping



B0


System bus rate



8 GT/s


Thermal Design Power (TDP)



54 Watt


Processor special features



Conflict-Free processor



Yes


Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Clear Video Technology



Yes


Intel Enhanced Halt State



Yes


Intel Identity Protection Technology version



1.00


Intel Secure Key Technology version



1.00


Intel Software Guard Extensions (Intel SGX)



Yes


Intel Stable Image Platform Program (SIPP)



No


Intel Stable Image Platform Program (SIPP) version



0


Intel Trusted Execution Technology



No


Intel TSX-NI



No


Intel TSX-NI version



0.00


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel� AES New Instructions (Intel� AES-NI)



Yes


Intel� Boot Guard



Yes


Intel� Clear Video HD Technology (Intel� CVT HD)



Yes


Intel� Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)



Yes


Intel� Hyper Threading Technology (Intel� HT Technology)



Yes


Intel� Identity Protection Technology (Intel� IPT)



Yes


Intel� InTru� 3D Technology



Yes


Intel� Memory Protection Extensions (Intel� MPX)



Yes


Intel� Optane� Memory Ready



No


Intel� OS Guard



Yes


Intel� Quick Sync Video Technology



Yes


Intel� Secure Key



Yes


Intel� Transactional Synchronization Extensions



No


Intel� Turbo Boost Technology



No


Intel� vPro� Platform Eligibility



No


Product dimensions



Net Weight (Product, kg)



0.23700000000000002 kg


Technical details



Bus bandwidth



8


Bus speed



8 GT/s


Bus type units



GT/s


Last change



63903513


Launch date



Q1'17


Maximum graphics card memory



64 GB


Maximum memory



64 GB


Maximum resolution & refresh rate (DisplayPort)



4096x2304@60Hz


Maximum resolution & refresh rate (HDMI)



4096x2304@24Hz


Maximum resolution & refresh rate (Integrated Flat Panel)



4096x2304@60Hz


Processor brand name



Intel Pentium


Processor cache



3072 KB


Processor ID



0x5902


Product family



Intel Pentium Processor


Product type



Processor


Status



Discontinued


Supported memory types



DDR4-SDRAM, DDR3L-SDRAM


Vendor information



Brand Name


Intel


Warranty



1 Year(s)


Weight & dimensions



Processor package size



37.5 x 37.5 mm
