Intel CM8070104282515 Core I9-10900T Processor 1.9 CM8070104282515

Intel� Optane� Memory Supported

Intel� Optane� memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel� Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel� Optane� memory requires specific hardware and software configuration.

Intel� Turbo Boost Technology

Intel� Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don�t.

Intel� vPro� Platform Eligibility

Intel� vPro� Technology is a set of security and manageability capabilities built into the processor aimed at addressing four critical areas of IT security: 1) Threat management, including protection from rootkits, viruses, and malware 2) Identity and web site access point protection 3) Confidential personal and business data protection 4) Remote and local monitoring, remediation, and repair of PCs and workstations.

Intel� Hyper-Threading Technology

Intel� Hyper-Threading Technology (Intel� HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel� Virtualization Technology (VT-x)

Intel� Virtualization Technology (VT-x) allows one hardware platform to function as multiple �virtual� platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel� Virtualization Technology for Directed I/O (VT-d)

Intel� Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium� processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel� VT-x with Extended Page Tables (EPT)

Intel� VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel� Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel� 64

Intel� 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.� Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Instruction Set

An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel�s instruction set this processor is compatible with.

Instruction Set Extensions

Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

Idle States

Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Enhanced Intel SpeedStep� Technology

Enhanced Intel SpeedStep� Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep� Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep� Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Thermal Monitoring Technologies

Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.

Intel� Identity Protection Technology

Intel� Identity Protection Technology is a built-in security token technology that helps provide a simple, tamper-resistant method for protecting access to your online customer and business data from threats and fraud. Intel� IPT provides a hardware-based proof of a unique user�s PC to websites, financial institutions, and network services; providing verification that it is not malware attempting to login. Intel� IPT can be a key component in two-factor authentication solutions to protect your information at websites and business log-ins.

Intel� Stable Image Platform Program (SIPP)

Intel� Stable Image Platform Program (Intel� SIPP) can help your company identify and deploy standardized, stable image PC platforms for at least 15 months.

Features



Commodity Classification Automated Tracking System (CCATS)



G077159


CPU configuration (max)



1


Embedded options available



No


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



5A992C


Idle States



Yes


Market segment



Desktop


Maximum number of PCI Express lanes



16


PCI Express CEM revision



3.0


PCI Express configurations



1x16, 2x8, 1x8+2x4


PCI Express slots version



3.0


Scalability



1S


Supported instruction sets



SSE4.1, SSE4.2, AVX 2.0


Thermal Monitoring Technologies



Yes


Thermal solution specification



PCG 2015B


Graphics



Discrete graphics card



No


Discrete graphics card model



Not available


Maximum on-board graphics card memory



64 GB


Number of displays supported (on-board graphics)



3


On-board graphics card



Yes


On-board graphics card 4K support



Yes


On-board graphics card base frequency



350 MHz


On-board graphics card DirectX version



12.0


On-board graphics card dynamic frequency (max)



1200 MHz


On-board graphics card maximum resolution (DisplayPort)



4096 x 2304 Pixels


On-board graphics card maximum resolution (eDP - Integrated Flat Panel)



4096 x 2304 Pixels


On-board graphics card maximum resolution (HDMI)



4096 x 2160 Pixels


On-board graphics card model



Intel� UHD Graphics 630


On-board graphics card OpenGL version



4.5


On-board graphics card refresh rate at maximum resolution (DisplayPort)



60 Hz


On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)



60 Hz


On-board graphics card refresh rate at maximum resolution (HDMI)



30 Hz


Logistics data



Harmonized System (HS) code



8542310001


Memory



ECC



No


Maximum internal memory supported by processor



128 GB


Memory channels



Dual-channel


Memory clock speeds supported by processor



2933


Memory types supported by processor



DDR4-SDRAM


Operational conditions



Tjunction



100 �C


Other features



Maximum internal memory



128 GB


Package dimensions



Gross Weight (Package, kg)



1.16 kg


Processor



Box



No


Component for



PC


Configurable TDP-down



25 Watt


Configurable TDP-down frequency



1.2 GHz


Cooler included



No


Generation



10th Generation


Memory bandwidth supported by processor (max)



45.8 GB/s


Processor ARK ID



199324


Processor base frequency



1.9 GHz


Processor boost frequency



4.6 GHz


Processor cache



20 MB


Processor cache type



Smart Cache


Processor codename



Comet Lake


Processor cores



10


Processor family



Intel� Core� i9


Processor generation



10th gen Intel� Core� i9


Processor lithography



14 nm


Processor manufacturer



Intel


Processor model



i9-10900T


Processor operating modes



64-bit


Processor socket



LGA 1200 (Socket H5)


Processor threads



20


System bus rate



8 GT/s


Thermal Design Power (TDP)



35 Watt


Processor special features



Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Clear Video Technology



Yes


Intel Software Guard Extensions (Intel SGX)



Yes


Intel Stable Image Platform Program (SIPP)



Yes


Intel Trusted Execution Technology



Yes


Intel Turbo Boost Max Technology 3.0



Yes


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel� AES New Instructions (Intel� AES-NI)



Yes


Intel� Boot Guard



Yes


Intel� Clear Video HD Technology (Intel� CVT HD)



Yes


Intel� Hyper Threading Technology (Intel� HT Technology)



Yes


Intel� Identity Protection Technology (Intel� IPT)



Yes


Intel� InTru� 3D Technology



Yes


Intel� Optane� Memory Ready



Yes


Intel� OS Guard



Yes


Intel� Quick Sync Video Technology



Yes


Intel� Secure Key



Yes


Intel� Thermal Velocity Boost



No


Intel� Transactional Synchronization Extensions



No


Intel� Turbo Boost Max Technology 3.0 frequency



4.6 GHz


Intel� Turbo Boost Technology



2.0


Intel� Turbo Boost Technology 2.0 frequency



4.5 GHz


Intel� vPro� Platform Eligibility



Yes


Product dimensions



Net Weight (Product, kg)



0.89 kg


Technical details



Bus speed



8 GT/s


Launch date



Q2'20


Maximum graphics card memory



64 GB


Maximum memory



128 GB


Maximum resolution & refresh rate (DisplayPort)



4096 x 2304@60Hz


Processor ID



0x9BC5


Product type



Processor


Status



Launched


Supported memory types



DDR4-SDRAM


Target market



Gaming, Content Creation


Vendor information



Brand Name


Intel


Warranty



1 Year(s)


Weight & dimensions



Processor package size



37.5 x 37.5 mm
