Intel CM8071504820605 Core I9-13900 Processor 36 Mb CM8071504820605

Intel� Gaussian & Neural Accelerator
Intel� Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel� GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel� Deep Learning Boost (Intel� DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel� Speed Shift Technology
Intel� Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel� Thermal Velocity Boost
Intel� Thermal Velocity Boost (Intel� TVB) is a feature that opportunistically and automatically increases clock frequency above single-core and multi-core Intel� Turbo Boost Technology frequencies based on how much the processor is operating below its maximum temperature and whether turbo power budget is available. The frequency gain and duration is dependent on the workload, capabilities of the processor and the processor cooling solution.

Intel� Turbo Boost Max Technology 3.0
Intel� Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

Intel� Hyper-Threading Technology
Intel� Hyper-Threading Technology (Intel� HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Enhanced Intel SpeedStep� Technology
Enhanced Intel SpeedStep� Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep� Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep� Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Features



Commodity Classification Automated Tracking System (CCATS)



740.17B1


CPU configuration (max)



1


Direct Media Interface (DMI) Revision



4.0


Embedded options available



Yes


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



5A992C


Idle States



Yes


Market segment



Desktop


Maximum number of PCI Express lanes



20


PCI Express configurations



1x16+1x4, 2x8+1x4


PCI Express slots version



5.0, 4.0


Scalability



1S


Supported instruction sets



SSE4.1, SSE4.2, AVX 2.0


Thermal Monitoring Technologies



Yes


Use conditions



PC/Client/Tablet, Workstation


Graphics



Discrete graphics card



No


Discrete graphics card model



Not available


Multi-Format Codec Engines



2


Number of displays supported (on-board graphics)



4


Number of execution units



32


On-board graphics card



Yes


On-board graphics card base frequency



300 MHz


On-board graphics card DirectX version



12.0


On-board graphics card dynamic frequency (max)



1650 MHz


On-board graphics card maximum resolution (DisplayPort)



7680 x 4320 Pixels


On-board graphics card maximum resolution (eDP - Integrated Flat Panel)



5120 x 3200 Pixels


On-board graphics card maximum resolution (HDMI)



4096 x 2160 Pixels


On-board graphics card model



Intel UHD Graphics 770


On-board graphics card OpenGL version



4.5


On-board graphics card outputs supported



Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1


On-board graphics card refresh rate at maximum resolution (DisplayPort)



60 Hz


On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)



120 Hz


On-board graphics card refresh rate at maximum resolution (HDMI)



60 Hz


Logistics data



Harmonized System (HS) code



8542310001


Memory



ECC



Yes


Maximum internal memory supported by processor



192 GB


Memory bandwidth (max)



89.6 GB/s


Memory channels



Dual-channel


Memory types supported by processor



DDR4-SDRAM, DDR5-SDRAM


Operational conditions



Tjunction



100 �C


Other features



Graphics output



eDP 1.4b, DP 1.4a, HDMI 2.1


L2 cache



32768 KB


Maximum internal memory



192 GB


Package dimensions



Gross Weight (Package, kg)



1.16 kg


Processor



Box



No


Bus type



DMI4


Efficient cores



16


Efficient-core base frequency



1.5 GHz


Efficient-core boost frequency



4.2 GHz


Maximum number of DMI lanes



8


Maximum turbo power



219 Watt


Memory bandwidth supported by processor (max)



89.6 GB/s


Performance cores



8


Performance-core base frequency



2 GHz


Performance-core boost frequency



5.2 GHz


Processor ARK ID



230499


Processor base power



65 Watt


Processor boost frequency



5.6 GHz


Processor cache



36 MB


Processor cache type



Smart Cache


Processor codename



Raptor Lake


Processor cores



24


Processor family



Intel� Core� i9


Processor generation



13th gen Intel� Core� i9


Processor manufacturer



Intel


Processor model



i9-13900


Processor operating modes



64-bit


Processor socket



LGA 1700


Processor threads



32


Processor special features



Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Stable Image Platform Program (SIPP)



Yes


Intel Trusted Execution Technology



Yes


Intel Turbo Boost Max Technology 3.0



Yes


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel vPro� Enterprise Platform Eligibility



Yes


Intel vPro� Essentials Platform Eligibility



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel� Active Management Technology (Intel� AMT)



Yes


Intel� Adaptive Boost Technology



Yes


Intel� AES New Instructions (Intel� AES-NI)



Yes


Intel� Boot Guard



Yes


Intel� Clear Video HD Technology (Intel� CVT HD)



Yes


Intel� Control-flow Enforcement Technology (CET)



Yes


Intel� Deep Learning Boost (Intel� DL Boost)



Yes


Intel� Gaussian & Neural Accelerator (Intel� GNA) 3.0



Yes


Intel� Hardware Shield Eligibility



Yes


Intel� Hyper Threading Technology (Intel� HT Technology)



Yes


Intel� One-Click Recovery



Yes


Intel� OS Guard



Yes


Intel� Quick Sync Video Technology



Yes


Intel� Remote Platform Erase (RPE)



Yes


Intel� Secure Key



Yes


Intel� Speed Shift Technology



Yes


Intel� Standard Manageability (ISM)



Yes


Intel� Thermal Velocity Boost



Yes


Intel� Thermal Velocity Boost Frequency



5.6 GHz


Intel� Thread Director



Yes


Intel� Threat Detection Technology (TDT)



Yes


Intel� Total Memory Encryption - Multi Key



Yes


Intel� Turbo Boost Max Technology 3.0 frequency



5.5 GHz


Intel� Turbo Boost Technology



2.0


Intel� Virtualization Technology with Redirect Protection (VT-rp)



Yes


Intel� Volume Management Device (VMD)



Yes


Intel� vPro� Platform Eligibility



Yes


Product dimensions



Net Weight (Product, kg)



0.89 kg


Technical details



Launch date



Q1'23


OpenCL version



3.0


Status



Launched


Target market



Gaming, Content Creation


Vendor information



Brand Name


Intel


Warranty



1 Year(s)


Weight & dimensions



Processor package size



45 x 37.5 mm
