Intel
Intel CM8071505092101 Core I3-13100T Processor 12 CM8071505092101
(No reviews yet)
Write a Review
- UPC:
- 0000000000000
- MPN:
- CM8071505092101
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Intel� Gaussian & Neural Accelerator
Intel� Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel� GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
Intel� Hyper-Threading Technology
Intel� Hyper-Threading Technology (Intel� HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.
Features
Commodity Classification Automated Tracking System (CCATS)
740.17B1
CPU configuration (max)
1
Direct Media Interface (DMI) Revision
4.0
Embedded options available
Yes
Execute Disable Bit
Yes
Export Control Classification Number (ECCN)
5A992C
Idle States
Yes
Market segment
Desktop
Maximum number of PCI Express lanes
20
PCI Express configurations
1x16+1x4, 2x8+1x4
PCI Express slots version
5.0, 4.0
Scalability
1S
Supported instruction sets
SSE4.1, SSE4.2, AVX 2.0
Thermal Monitoring Technologies
Yes
Use conditions
PC/Client/Tablet
Graphics
Discrete graphics card
No
Discrete graphics card model
Not available
Multi-Format Codec Engines
1
Number of displays supported (on-board graphics)
4
Number of execution units
24
On-board graphics card
Yes
On-board graphics card base frequency
300 MHz
On-board graphics card DirectX version
12.0
On-board graphics card dynamic frequency (max)
1500 MHz
On-board graphics card maximum resolution (DisplayPort)
7680 x 4320 Pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
5120 x 3200 Pixels
On-board graphics card maximum resolution (HDMI)
4096 x 2160 Pixels
On-board graphics card model
Intel UHD Graphics 730
On-board graphics card OpenGL version
4.5
On-board graphics card outputs supported
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)
60 Hz
Logistics data
Harmonized System (HS) code
8542310001
Memory
Maximum internal memory supported by processor
192 GB
Memory bandwidth (max)
76.8 GB/s
Memory channels
Dual-channel
Memory types supported by processor
DDR4-SDRAM, DDR5-SDRAM
Operational conditions
Tjunction
100 �C
Other features
Graphics output
eDP 1.4b, DP 1.4a, HDMI 2.1
L2 cache
5120 KB
Maximum internal memory
192 GB
Package dimensions
Gross Weight (Package, kg)
1.16 kg
Processor
Box
No
Bus type
DMI4
Maximum number of DMI lanes
8
Maximum turbo power
69 Watt
Memory bandwidth supported by processor (max)
76.8 GB/s
Performance cores
4
Performance-core base frequency
2.5 GHz
Performance-core boost frequency
4.2 GHz
Processor ARK ID
230579
Processor base power
35 Watt
Processor boost frequency
4.2 GHz
Processor cache
12 MB
Processor cache type
Smart Cache
Processor codename
Raptor Lake
Processor cores
4
Processor family
Intel� Core� i3
Processor generation
Intel Core i3-13xxx
Processor manufacturer
Intel
Processor model
i3-13100T
Processor operating modes
64-bit
Processor socket
LGA 1700
Processor threads
8
Stepping
H0
Processor special features
Enhanced Intel SpeedStep Technology
Yes
Intel 64
Yes
Intel Turbo Boost Max Technology 3.0
No
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel� AES New Instructions (Intel� AES-NI)
Yes
Intel� Boot Guard
Yes
Intel� Clear Video HD Technology (Intel� CVT HD)
Yes
Intel� Control-flow Enforcement Technology (CET)
Yes
Intel� Deep Learning Boost (Intel� DL Boost)
Yes
Intel� Gaussian & Neural Accelerator (Intel� GNA) 3.0
Yes
Intel� Hyper Threading Technology (Intel� HT Technology)
Yes
Intel� OS Guard
Yes
Intel� Quick Sync Video Technology
Yes
Intel� Secure Key
Yes
Intel� Speed Shift Technology
Yes
Intel� Standard Manageability (ISM)
Yes
Intel� Thread Director
No
Intel� Turbo Boost Technology
2.0
Intel� Volume Management Device (VMD)
Yes
Product dimensions
Net Weight (Product, kg)
0.89 kg
Technical details
Launch date
Q1'23
OpenCL version
3.0
Status
Launched
Vendor information
Brand Name
Intel
Warranty
1 Year(s)
Weight & dimensions
Processor package size
45 x 37.5 mm
