Intel Core i9-14900KF Intel® Core™ i9 LGA 1700 Intel i9-14900KF 64-bit Intel Cor BX8071514900KF

Intel Core i9-14900KF. Processor family: Intel® Core™ i9, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.8 GHz, Intel® Thermal Velocity Boost Frequency: 6 GHz. Processor package size: 45 x 37.5 mm

Graphics


On-board graphics card

No


On-board graphics card model

Not available


Discrete graphics card

No


Discrete graphics card model

Not available



Processor special features


Mode-based Execute Control (MBE)

Yes


Enhanced Intel SpeedStep Technology

Yes


Intel® Speed Shift Technology

Yes


Intel® Thermal Velocity Boost

Yes


Intel® Gaussian & Neural Accelerator (Intel® GNA) 3?0

Yes


Intel® Hyper Threading Technology (Intel® HT Technology)

Yes


Intel Turbo Boost Max Technology 3?0

Yes


Intel® Turbo Boost Technology

2.0


Intel® Thermal Velocity Boost Frequency

6 GHz


Intel® Control-flow Enforcement Technology (CET)

Yes


Intel® Volume Management Device (VMD)

Yes


Intel® Adaptive Boost Technology

Yes


Intel® Standard Manageability (ISM)

Yes


Intel® Thread Director

Yes


Intel® Boot Guard

Yes


Intel Virtualization Technology for Directed I/O (VT-d)

Yes


Intel® OS Guard

Yes


Intel Virtualization Technology (VT-x)

Yes


Intel® Secure Key

Yes


Intel® Turbo Boost Max Technology 3?0 frequency

5.8 GHz


Intel® AES New Instructions (Intel® AES-NI)

Yes


Intel® Deep Learning Boost (Intel® DL Boost)

Yes


Intel VT-x with Extended Page Tables (EPT)

Yes


Intel 64

Yes



Processor


Processor base power
5 W


Processor operating modes

64-bit


Performance cores

8


Performance-core base frequency

3.2 GHz


Maximum turbo power

253 W


Processor family

Intel® Core™ i9


Stepping

B0


Processor socket

LGA 1700


Processor boost frequency

6 GHz


Processor ARK ID

236787


Efficient-core base frequency

2.4 GHz


Processor generation

Intel Core i9-14xxx


Processor threads

32


Processor codename

Raptor Lake


Processor cache

36 MB


Memory bandwidth supported by processor (max)

89.6 GB/s


Box

Yes


Efficient-core boost frequency

4.4 GHz


Efficient cores



Processor cache type

Smart Cache


Maximum number of DMI lanes

8


Performance-core boost frequency

5.6 GHz


Cooler included

No


Processor model

i9-14900KF


Processor manufacturer

Intel


Processor cores

24



Weight & dimensions


Processor package size

45 x 37.5 mm



Logistics data


Harmonized System (HS) code

8542310001



Memory


Memory types supported by processor

DDR4-SDRAM, DDR5-SDRAM


Memory bandwidth (max)

89.6 GB/s


Non-ECC

Yes


Maximum internal memory supported by processor
2 GB


Memory channels

Dual-channel



Technical details


Status

Launched


Launch date

Q4'23



Other features


L2 cache

32768 KB


Maximum internal memory
2 GB



Features


Use conditions

PC/Client/Tablet


Direct Media Interface (DMI) Revision

4.0


Scalability

1S


Commodity Classification Automated Tracking System (CCATS)

740.17B1


Embedded options available

No


Execute Disable Bit

Yes


Export Control Classification Number (ECCN)

5A992C


Thermal Monitoring Technologies

Yes


PCI Express slots version

4.0, 5.0


Idle States

Yes


Supported instruction sets

AVX 2.0, SSE4.1, SSE4.2


Maximum number of PCI Express lanes



Market segment

Desktop


PCI Express configurations

1x16+1x4, 2x8+1x4


CPU configuration (max)

1


Thermal solution specification

PCG 2020A



Operational conditions


Tjunction
0 °C
