Intel HH80555KH0884M-RFB Xeon 5060 3.2 GHz. 130W HH80555KH0884M-RFB

Designed for industry-leading performance and maximum energy efficiency, these versatile 1-way and 2-way 64-bit multi-core servers and workstations are ideally suited to a wide range of infrastructure, cloud, high-density, and high performance computing (HPC) applications.

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Features



Commodity Classification Automated Tracking System (CCATS)



NA


Embedded options available



No


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



3A991.A.1


Harmonized System (HS) code



8542310001


Idle States



No


Images Type Map



divimg src="https://ark.intel.com/inc/images/diagrams/diagram-5.gif" title="Block Diagram" /img src="https://ark.intel.com/inc/images/diagrams/diagram-6.gif" title="Block Diagram" //div


Market segment



Server


Number of Processing Die Transistors



376 M


Processing Die size



162 mm²


Operational conditions



Maximum operating temperature



78 °C


Tcase



78 °C


Package dimensions



Gross Weight (Package, kg)



1.2 kg


Power



Thermal Design Power (TDP)



150 Watt


VID Voltage Range



1.075 - 1.350 V


Processor



Box



No


Bus type



FSB


Component for



Server/workstation


Cooler included



No


CPU multiplier (bus/core ratio)



12


FSB Parity



Yes


Processor ARK ID



27211


Processor base frequency



3.2 GHz


Processor cache



4 MB


Processor cache type



L2


Processor codename



Dempsey


Processor cores



2


Processor family



Intel® Xeon®


Processor frequency



3.2 GHz


Processor front side bus



1066 MHz


Processor lithography



65 nm


Processor manufacturer



Intel


Processor model



5060


Processor operating modes



64-bit


Processor series



Intel Xeon 5000 Series


Processor socket



LGA 771 (Socket J)


Processor threads



4


Thermal Design Power (TDP)



130 Watt


VID Voltage Range



1.075 - 1.35 V


Processor special features



Conflict-Free processor



No


Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Demand Based Switching



No


Intel Enhanced Halt State



No


Intel Trusted Execution Technology



No


Intel Virtualization Technology (VT-x)



Yes


Intel VT-x with Extended Page Tables (EPT)



No


Intel® Hyper Threading Technology (Intel® HT Technology)



Yes


Intel® Turbo Boost Technology



No


Product dimensions



Net Weight (Product, kg)



1 kg


Technical details



Bus bandwidth



1066


Bus speed



1066 MHz


Bus type units



MHz


Last change



63903513


Processor brand name



Intel Xeon


Processor cache



4096 KB


Product family



Intel Xeon Processor 5000 Sequence


Product type



Processor


Status



Discontinued


Vendor information



Brand Name


Intel


Warranty



1 Year(s)


Weight & dimensions



Processor package size



37.5 x 37.5 mm
