Intel PK8071305121601 Xeon Silver 4410T Processor PK8071305121601

Intel� Trusted Execution Technology
Intel� Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel� processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

Intel� Virtualization Technology for Directed I/O (VT-d)
Intel� Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium� processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel� Virtualization Technology (VT-x)
Intel� Virtualization Technology (VT-x) allows one hardware platform to function as multiple �virtual� platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel� 64
Intel� 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.� Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Cache
CPU Cache is an area of fast memory located on the processor. Intel� Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

Intel� AES New Instructions
Intel� AES New Instructions (Intel� AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel� Turbo Boost Technology
Intel� Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don�t.

Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel� Turbo Boost Technology and, if present, Intel� Turbo Boost Max Technology 3.0 and Intel� Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

Intel� Hyper-Threading Technology
Intel� Hyper-Threading Technology (Intel� HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel� VT-x with Extended Page Tables (EPT)
Intel� VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel� Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

Intel� Speed Shift Technology
Intel� Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel� Crypto Acceleration
Intel� Crypto Acceleration reduces the performance impact of pervasive encryption and increases the performance of encryption-intensive workloads including SSL web serving, 5G infrastructure, and VPN/firewalls.

Intel� Software Guard Extensions (Intel� SGX)
Intel� Software Guard Extensions (Intel� SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications� sensitive routines and data. Intel� SGX provides developers a way to partition their code and data into CPU hardened trusted execution environments (TEE�s).

Intel� Speed Select Technology � Core Power
Enables flexibility for workloads that benefit from higher base frequency on a subset of the processor�s cores. While the max turbo frequency across the cores remain constant across the cores, a subset of the cores can be assigned as to run at a higher base frequency than specified, while the other cores run at lower base frequency.

Intel� Deep Learning Boost (Intel� DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

Intel� Total Memory Encryption
TME � Total Memory Encryption (TME) helps protect data against exposure via physical attack on memory, such as cold-boot attacks.

Max # of UPI Links
Intel� Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel� QPI.

# of AVX-512 FMA Units
Intel� Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.

Intel� Resource Director Technology (Intel� RDT)
Intel� RDT brings new levels of visibility and control over how shared resources such as last-level cache (LLC) and memory bandwidth are used by applications, virtual machines (VMs) and containers.

Intel� Speed Select Technology - Performance Profile
A capability to configure the processor to run at three distinct operating points.

Mode-based Execute Control (MBEC)
Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

Intel� Boot Guard
Intel� Device Protection Technology with Boot Guard helps protect the system�s pre-OS environment from viruses and malicious software attacks.

Intel� Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.

Intel� Transactional Synchronization Extensions
Intel� Transactional Synchronization Extensions (Intel� TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.

Features



Commodity Classification Automated Tracking System (CCATS)



G180729


Embedded options available



Yes


Execute Disable Bit



Yes


Export Control Classification Number (ECCN)



5A992C


Market segment



Server


Maximum number of PCI Express lanes



80


PCI Express slots version



5.0


Scalability



2S


Supported instruction sets



AMX, SSE4.2, AVX, AVX 2.0, AVX-512


Use conditions



Industrial Commercial Temp, Server/Enterprise


Graphics



Discrete graphics card



No


Discrete graphics card model



Not available


On-board graphics card



No


On-board graphics card model



Not available


Logistics data



Harmonized System (HS) code



8542310001


Memory



ECC



Yes


Maximum internal memory supported by processor



6 TB


Memory channels



Octa-channel


Memory types supported by processor



DDR4-SDRAM


Operational conditions



DTS Max



100 �C


Tcase



84 �C


Other features



Maximum internal memory



4 TB


Package dimensions



Gross Weight (Package, kg)



1.16 kg


Processor



Box



No


Processor ARK ID



232388


Processor base frequency



2.7 GHz


Processor boost frequency



4 GHz


Processor cache



26.25 MB


Processor codename



Sapphire Rapids


Processor cores



10


Processor family



Intel Xeon Silver


Processor generation



Intel Xeon Scalable 4th Gen


Processor manufacturer



Intel


Processor model



4410T


Processor operating modes



64-bit


Processor socket



LGA 4677 (Socket E)


Processor threads



20


Stepping



S3


System bus rate



16 GT/s


Thermal Design Power (TDP)



150 Watt


Processor special features



AVX-512 Fused Multiply-Add (FMA) units



2


Intel 64



Yes


Intel Software Guard Extensions (Intel SGX)



Yes


Intel Trusted Execution Technology



Yes


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Intel� Advanced Matrix Extensions (AMX)



Yes


Intel� AES New Instructions (Intel� AES-NI)



Yes


Intel� Boot Guard



Yes


Intel� Control-flow Enforcement Technology (CET)



Yes


Intel� Crypto Acceleration



Yes


Intel� Data Streaming Accelerator (DSA)



1 default devices


Intel� Deep Learning Boost (Intel� DL Boost)



Yes


Intel� Hyper Threading Technology (Intel� HT Technology)



Yes


Intel� On Demand Feature Activation



Yes


Intel� OS Guard



Yes


Intel� Platform Firmware Resilience Support



Yes


Intel� QuickAssist Software Acceleration



Yes


Intel� Speed Select technology - Performance Profile (Intel� SST-PP)



Yes


Intel� Speed Shift Technology



Yes


Intel� Total Memory Encryption



Yes


Intel� Transactional Synchronization Extensions



Yes


Intel� Turbo Boost Technology



2.0


Maximum Enclave Size Support for Intel� SGX



64 GB


Product dimensions



Net Weight (Product, kg)



0.89 kg


Technical details



Launch date



Q1'23


Memory speed (max)



4000 MHz


Number of UPI links



2


Package carrier



E1B


Status



Launched


Vendor information



Brand Name


Intel


Warranty



1 Year(s)


Weight & dimensions



Processor package size



77.5 x 56.5 mm
