Intel X550T2G1P5 X550-T2 Internal Ethernet X550T2G1P5

Intel� Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel� Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.

Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.

Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.

Design



Internal



Yes


Product colour



Green, Silver


Network



Cabling technology



10GBase-T


Ethernet interface type



5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet


Ethernet LAN



Yes


Ethernet LAN data rates



100, 1000, 2500, 5000, 10000


iSCSI support



Yes


LAN controller



Intel� X550


Maximum data transfer rate



10000 Mbit/s


Networking standards



IEEE 802.1Q, IEEE 802.1as, IEEE 802.1p, IEEE 802.3, IEEE 802.3ad


VLAN tagging



Yes


Operational conditions



Operating temperature (T-T)



0 - 55 �C


Storage relative humidity (H-H)



0 - 90 %


Storage temperature (T-T)



-40 - 70 �C


Other features



Cable type



RJ-45 Category-6 up to 55m; Category-6A up to 100m


Data transfer rate



8 GT/s


Desktop Management Interface (DMI) version



2.0


Ethernet adapter ARK ID



88209


Fiber Channel over Ethernet



Yes


Intel Data Direct I/O Technology



Yes


Intel Flexible Port Partitioning



Yes


Intel Virtual Machine Device Queues (VMDq)



Yes


Intel Virtualization Technology for Connectivity (VT-c)



Yes


Intelligent Offloads



Yes


Interface type



PCIe v3.0 (8.0GT/s)


iWARP/RDMA



No


Number of VLANs



4096


On-chip QoS and Traffic Management



Yes


PCI-SIG* SR-IOV Capable



Yes


Product family



Intel 10 Gigabit server adapter


Product series



Intel� Ethernet Converged Network Adapter X550 Series


Product type



13


Status



Launched


Package dimensions



Gross Weight (Package, kg)



0.26 kg


Ports & interfaces



Connectivity technology



Wired


Ethernet LAN (RJ-45) ports



2


Host interface



PCI Express


Interface



Ethernet


PCI Card form factor



Half-height (low-profile)


Product dimensions



Net Weight (Product, kg)



0.2 kg


System requirements



Compatible operating systems



intel.com/support/EthernetOS


Linux operating systems supported



Red Hat Enterprise Linux WS 5.0, Red Hat Enterprise Linux WS 6.0, SUSE Linux Enterprise Desktop 10, SUSE Linux Enterprise Desktop 11


Server operating systems supported



Windows Server 2003, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012 R2, Windows Server 2012 R2 x64


Windows operating systems supported



Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64


Vendor information



Brand Name


Intel


Warranty



1 Year(s)
