Intellinet 530378 5-Port Gigabit Ethernet 530378

Easy to install, with auto-learning capabilities. _x000D_
_x000D_
The Intellinet Network Solutions Gigabit Ethernet Switch is perfect for the home or small office, delivering top speeds to the desktop to satisfy your demanding network needs. _x000D_
_x000D_
High-Speed Performance _x000D_
This desktop switch includes five Gigabit Ethernet ports, providing you with high performance on your network to handle quick transfer speeds that support disk mirroring, data backup, graphics image file transfers and other bandwidth-intensive applications. _x000D_
_x000D_
Auto Features _x000D_
This network LAN switch includes many automatic features that make it easy to use. No configuration is required, so installation is Plug and Play and hassle free. Auto-MDI/MDI-X crossover on all ports eliminates the need for any crossover cables. Each of the five ports on this network LAN switch automatically senses the link speed of the connected network device and adjusts to 10, 100 or 1000 Mbps for compatibility and maximum performance. _x000D_
_x000D_
Reliable Operation _x000D_
The Intellinet Network Solutions Gigabit Ethernet Switch supports flow control when operating in half duplex mode and IEEE 802.3ab in full duplex mode to ensure that data transfer and network connectivity run smoothly and uninterrupted. In conjunction with the broadcast storm control and the store and forward switching method, flow control further ensures that your connections remain active even under extremely busy conditions.

Data transmission



Jumbo frames support



Yes


MAC address table



1024 entries


Packet buffer memory



0.112 MB


Store-and-forward



Yes


Design



Certification



FCC Class B, CE, RoHS


LED indicators



Y, Yes


Product colour



Black


Stackable



No


Logistics data



Harmonized System (HS) code



85176990


Network



10G support



No


Auto MDI/MDI-X



Yes


Flow control support



Yes


Full duplex



Yes


Networking standards



IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 °C


Storage temperature (T-T)



-20 - 90 °C


Package dimensions



Gross Weight (Package, kg)



0.65 kg


Packaging data



Manual



Yes


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



5


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


Power connector



DC-in jack


Power



DC input voltage



5 V


Input current



1 A


Power supply included



Yes


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



7.8 cm


Product Height



2.8 cm


Product Width



14 cm


Security



MAC address filtering



Yes


Vendor information



Brand Name


Intellinet


Warranty



1 Year(s)
