Inter-Tech
Inter-Tech 88882179 Argusnt Bps-700 Power Supply 88882179
- UPC:
- 0000000000000
- MPN:
- 88882179
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
The BPS series from Argus stands for powerful and reliable power supplies in the levels of 500W, 600W and 700W. To upgrade existing systems or to configure new ones, thanks to 80PLUS� Bronze 230V EU certification and state-of-the-art components, the BPS series will keep you up to date. To secure the built-in hardware and the power supply unit itself, we have not made any compromises and have equipped the power supply units of the BPS series with a total of five protective circuits (OPP, SCP, OVP, OCP and NLP).
When it comes to the variety of connections, we also kept an eye on the greatest possible efficiency and, with the exception of the 20+4pin connection, designed all other cable strands as flat ribbon versions - saving space and time when laying. The BPS-700 has four PCIe 6+2pin and six S-ATA connections available. With 58A on the 12V line, there is more than enough power available for potent hardware.
The overall package is rounded off by the smooth-running 120mm fan and the 36-month manufacturer's guarantee for the entire BPS series.
Design
Fan diameter
12 cm
Product colour
Black
Logistics data
Harmonized System (HS) code
84733020
Package dimensions
Gross Weight (Package, kg)
2.31 kg
Performance
80 PLUS certification
80 PLUS Bronze
ATX version
2.4
Noise level
39.8 dB
Power supply unit (PSU) form factor
ATX
Purpose
PC
Ports & interfaces
ATX power connector (20+4 pin)
Yes
CPU power connector (4+4 pin)
Yes
Floppy disk drive connector
Yes
Floppy drive power connector
1
Motherboard power connector
20+4 pin ATX
Number of SATA power connectors
6
PCI Express connector
Yes
PCI Express power connectors (6+2 pin)
4
Peripheral (Molex) power connectors (4-pin)
3
Power
AC input frequency
47 - 63 Hz
AC input voltage
100 - 240 V
Combined power (-12V)
3.6 Watt
Combined power (+12V)
620 Watt
Combined power (+3.3V)
100 Watt
Combined power (+5V)
100 Watt
Combined power (+5Vsb)
12.5 Watt
Efficiency
88.9 %
Input current
9/4.5 A
Max output current (-12V)
0.3 A
Max output current (+12V)
58 A
Max output current (+3.3V)
15 A
Max output current (+5V)
15 A
Max output current (+5Vsb)
2.5 A
Power protection features
Over current, Over power, Over voltage, Short circuit
Total power
700 Watt
Product dimensions
Net Weight (Product, kg)
1.78 kg
Product Depth
14 cm
Product Height
8.6 cm
Product Width
15 cm
Vendor information
Brand Name
Inter-Tech
Warranty
1 Year(s)
