IOGEAR GCS1794MDPKIT GCS1794 and GMDPHDW6 Bundle GCS1794MDPKIT

HDMI and Mini DisplayPort Mix & Match Solution
IOGEAR's HD and Mini DisplayPort KVM Solution enables effortless control over 4 HDMI or Mini DisplayPort computers using a single USB keyboard, USB mouse and single high definition display (720P or 1080P) or HDTV. This bundle is perfect for a home office or small / medium size business, as it offers the flexibility of choosing between HD and/or Mini DisplayPort connections. The HDMI - Mini DisplayPort KVM bundle enables effortless control over 4 HD or Mini DisplayPort devices or computers using a single USB keyboard, USB mouse and single high definition display or HDTV. Use the included adaptors connect your Mini DisplayPort enabled Apple� MacBook�, MacBook Pro�, MacBook Air�, iMac� or Microsoft Surface� to an external HDMI based projector or display.

HD Technology
Connect your high definition display with HDMI connections, HDTV (flat panel, plasma, DLP, digital TV) and data projectors. The 4-Port HD KVMP Switch is HDCP compliant and equipped with IOGEAR's DynaSync*. This feature reads and remembers the monitor's parameters (EDID), eliminating any delays or change in video resolution when switching between, or booting computers.

IOGEAR's advanced HDMI KVMP can increase efficiency and save equipment cost for applications where HD resolutions, large or widescreen monitors with HDMI connections are used and required:
Expanded Connectivity
IOGEAR's Mini DisplayPort to HDMI adapter supports the DisplayPort 1.1a standard, giving you the ability to send high resolution video up to 1920x1200 to your external HDMI display or projector. The 4-Port HDMI KVM Switch features two USB 2.0 peripheral ports for asynchronously sharing USB devices between your computers. The patented asynchronous switching allows the user to independently switch applications between the connected computers. You can run one application on one computer while running another application on the other. A powered USB hub may be attached to the peripheral ports for added functionality. This HD - Mini DisplayPort KVM bundle offers a simple Plug-N-Play out-of-box solution; including all cabling required for �Set-up and Go�!

IOGEAR's Mini DisplayPort to HDMI adapter supports audio pass through, eliminating the need for additional cabling to get audio signals from your Mini DisplayPort device to your HDTV or projector.

Design



Housing material



Metal


LED indicators



Y, Yes


Product colour



Black, White


Display



Built-in display



No


Operational conditions



Operating temperature (T-T)



0 - 50 �C


Storage temperature (T-T)



-20 - 60 �C


Package dimensions



Depth (package,cm)



10.16 cm


Gross Weight (Package, kg)



0.17 kg


Height (package,cm)



21.59 cm


Width (package,cm)



33.02 cm


Packaging content



AC adapter included



Yes


Cables included



KVM


Manual



Yes


Performance



Maximum digital resolution



1920 x 1200 Pixels


Maximum resolution



1920 x 1200 Pixels


Plug and Play



Yes


Scan interval



99


Ports & interfaces



Audio connections



Yes


Console ports



3.5mm headphone, 3.5mm mic, HDMI


DC-in jack



Yes


Display connection



Yes


HDCP



Yes


HDMI ports quantity



4


Headphone outputs



4


Keyboard port type



USB


Mouse port type



USB


Number of computers controlled



4


USB 2.0 ports quantity



8


USB connector type



USB Type-A, USB Type-B


USB hub



Yes


USB version



USB 2.0


Video port type



HDMI


Power



External power adapter



Yes


Product dimensions



Net Weight (Product, kg)



0.16 kg


Product Depth



4.13 cm


Product Height



26.03 cm


Product Width



7.62 cm


System requirements



Linux operating systems supported



Yes


Mac operating systems supported



Mac OS 9.0, Mac OS 9.1, Mac OS 9.2, Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks


Windows operating systems supported



Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64


Vendor information



Brand Name


IOGEAR


Homepage



http://www.iogear.com


Warranty



3 Year(s)
