Kingston IKKP200/128GB Technology IronKey Keypad 200 IKKP200/128GB

Kingston IronKey� Keypad 200 is an OS-independent hardware-encrypted USB drive with an alphanumeric keypad for easy-to-use PIN access.

KP200 incorporates XTS-AES 256-bit hardware-based encryption. It is also FIPS 140-3 Level 3 (pending) certified for military-grade security with enhancements that further elevate the bar for data protection. Its circuitry is covered by a layer of special epoxy that makes it virtually impossible to remove components without damaging them; this tough epoxy stops attacks against the semiconductor components. The drive is designed to be tamper evident to alert owners. It also incorporates brute force password attack protection, and BadUSB protection with digitally signed firmware. The alphanumeric keypad is coated with a layer of polymer that protects the keys and hides key usage through analysis of fingerprints on the keys.

KP200 utilises a built-in rechargeable battery that can be used to unlock the drive first without using any software, and then plug it into any device that supports a USB type A mass storage device. This gives users the most flexibility across different platform types and operating systems.

With Multi-PIN option (Admin/User), the keypad can be used to set up an easy-to-remember but hard-to guess alphanumeric PIN for Admin or User. Admin can restore a User PIN and provide access to the drive should the User PIN be forgotten, or if the drive is locked after reaching the maximum of 10 User login attempts. With both Admin and User PINs enabled, KP200 will lock the User PIN after 10 failed login attempts; if the Admin PIN is entered incorrectly 10 times in a row, brute force attack protection will crypto-erase the drive, destroy the data forever, and reset it.

The drive also provides two levels of Read-Only (or Write-Protect) modes � a Global mode that can be set by Admin, and a session-only mode that can be set by User. Read-Only modes can protect the drive from malware on untrusted systems. In addition, Admin can load content and set Global Read-Only mode, so that User can access the data but not make any changes.

FIPS 140-3 Level 3 (pending) certified
KP200 now meets the new FIPS 140-3 Level 3 military-grade security specifications published by NIST. This is an enhanced version of the FIPS 140-2 specifications that further enhances the drive�s security capabilities and tamper resistance. It includes XTS-AES 256-bit encryption along with brute force and BadUSB attack protection with digitally signed firmware. Its circuitry is covered by a layer of special epoxy that makes it virtually impossible to remove components without damaging them; this tough epoxy stops attacks against the semiconductor components.

OS and device independent
With KP200 utilising a rechargeable battery, the keypad can be used to unlock the drive without using any software, and then plug it into any system that supports a USB Type-A mass storage device. This gives users the most flexibility across different platform types and operating systems.

Multi-PIN option
Users have the option to set up a User or an Admin/User mode. Admin can be used to restore a User PIN and provide access to the drive should User PIN be forgotten or if the drive is locked after reaching the maximum of 10 User login attempts.

Global and Session Read-Only (write protect) modes
Both Admin and User can set a session-based Read-Only mode to protect the drive from malware on untrusted systems. Admin can also set a Global Read-Only mode that sets the drive in Read-Only mode until reset.

Design



Form factor



Sleeve


International Protection (IP) code



IP68


Key ring



Yes


LED indicators



Pin


Product colour



Blue


Protection features



Waterproof, Dust resistant


Logistics data



Master (outer) case gross weight



463.58 g


Master (outer) case height



6.99 cm


Master (outer) case length



20.32 cm


Master (outer) case width



13.59 cm


Products per master (outer) case



8 pc(s)


Operational conditions



Operating temperature (T-T)



0 - 50 �C


Storage temperature (T-T)



-20 - 60 �C


Package dimensions



Depth (package,cm)



1.24 cm


Gross Weight (Package, kg)



0.07 kg


Height (package,cm)



18.42 cm


Width (package,cm)



12.95 cm


Packaging content



Quantity per pack



1 pc(s)


Performance



Capacity



128 GB


Compatible operating systems



Microsoft Windows, macOS, Linux, Chrome OS, Android


Device interface



USB Type-A


Plug and Play



Yes


Read speed



145 MB/s


USB version



3.2 Gen 1 (3.1 Gen 1)


Write speed



115 MB/s


Product dimensions



Net Weight (Product, kg)



0.05 kg


Product Depth



1.05 cm


Product Height



2 cm


Product Width



8 cm


Security



Hardware encryption



Yes


Keypad integrated



Yes


Keypad number of keys



11


Password protection



Yes


PIN-secured access



Yes


Read-only function



Yes


Security algorithms



FIPS 140-3, 256-bit AES-XTS


User and admin roles



Yes


Vendor information



Brand Name


Kingston


Warranty



1 Year(s)
