KIOXIA KCMYXVUG12T8 CM7-V 2.5" 12.8 TB PCI KCMYXVUG12T8

Enterprise NVMe� Mixed-use SSD
KIOXIA CM7-V Series is a mixed-use SSD that is optimized to support a broad range of enterprise applications and associated workloads, including high performance computing, online transaction processing, IoT and edge computing, media streaming. Built on PCIe� 5.0 (for U.3 host: PCIe� 4.0) and NVMe� 2.0 technology, the CM7 Series SSDs deliver excellent performance up to 2,700K IOPS (random read) and 600K IOPS (random write).

Featuring KIOXIA 112-layer BiCS FLASH� 3D TLC flash memory, the CM7-V Series of enterprise NVMe� SSDs delivers 3 DWPD (Drive Writes Per Day) of endurance and supports storage capacities up to 12.8 TB, making them ideally suited for read and write mixed-use enterprise applications.

Features



Component for



Server/workstation


Hardware encryption



Yes


Interface



PCI Express 5.0


Market segment



Server


Mean time between failures (MTBF)



2500000 Hour


Memory type



BiCS FLASH TLC


NVMe



Yes


NVMe version



2.0


Power loss protection



Yes


Random read (4KB)



2400000 IOPS


Random write (4KB)



550000 IOPS


Read speed



14000 MB/s


SSD capacity



13 TB


SSD form factor



2.5"


Target workload



Mixed Use (MU)


Use conditions



Server/Enterprise


Write speed



7000 MB/s


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating shock



1 kg


Operating temperature (T-T)



0 - 73 �C


Operating vibration



2.17 G


Storage temperature (T-T)



-40 - 85 �C


Package dimensions



Gross Weight (Package, kg)



0.91 kg


Power



Operating voltage



12 V


Power consumption (average)



25 Watt


Power consumption (standby)



5 Watt


Product dimensions



Net Weight (Product, kg)



0.7 kg


Product Depth



1.5 cm


Product Height



10.04 cm


Product Width



6.98 cm


Vendor information



Brand Name


KIOXIA


Warranty



1 Year(s)
