LC-POWER LC550 V2.31 Power Supply Unit 550 W LC550 V2.31

LC550 V2.31 - Platinum Series

Design



Fan diameter



13.5 cm


Number of fans



1 fan(s)


Product colour



Black


Logistics data



Harmonized System (HS) code



84733020


Package dimensions



Gross Weight (Package, kg)



0.65 kg


Performance



80 PLUS certification



80 PLUS Titanium


ATX version



2.31


Certification



CE / T�V


Power supply unit (PSU) form factor



ATX


Purpose



PC


Ports & interfaces



CPU power cable length



0.55 mm


CPU power connector (4+4 pin)



Yes


Motherboard power cable length



55 cm


Motherboard power connector



24-pin ATX


Number of PATA power connectors



6


Number of SATA power connectors



6


PCI Express power cable length



60 cm


PCI Express power connectors (6+2 pin)



4


SATA power cable length



350, 550, 700, 850


Power



Combined power (+3.3V)



20 Watt


Max output current (+12V)



45 A


Max output current (+5V)



20 A


Power Factor Correction (PFC) type



Active


Power protection features



Over current, Over power, Over voltage, Short circuit, Under voltage


Total power



550 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



16.4 cm


Product Height



8.6 cm


Product Width



15 cm


Vendor information



Brand Name


LC-POWER


Warranty



1 Year(s)
