Lenovo 00D9550-RFB Mellanox ConnectX-3 FDR VPI 00D9550-RFB

High-performance computing (HPC) solutions require high bandwidth, low latency components with CPU offloads to get the highest server efficiency and application productivity. The Mellanox ConnectX-3 and ConnectX-3 Pro network adapters for System x� servers deliver the I/O performance that meets these requirements.

Mellanox's ConnectX-3 and ConnectX-3 Pro ASIC delivers low latency, high bandwidth, and computing efficiency for performance-driven server applications. Efficient computing is achieved by offloading from the CPU routine activities, which makes more processor power available for the application. Network protocol processing and data movement impacts, such as InfiniBand RDMA and Send/Receive semantics, are completed in the adapter without CPU intervention. RDMA support extends to virtual servers when SR-IOV is enabled. Mellanox's ConnectX-3 advanced acceleration technology enables higher cluster efficiency and scalability of up to tens of thousands of nodes.

Design



Certification



EN55022 EN55024 EN60950-1 EN 61000-3-2 EN 61000-3-3 IEC 60950-1 FCC Part 15 Class A UL 60950-1 CSA C22.2 60950-1-07 VCCI NZ AS3548 / C-tick RRL for MIC (KCC) BSMI (EMC) IECS-003:2004 Issue 4


Compatible products



x3500 M5, x3550 M5, x3650 M5, x3850 X6/x3950 X6, nx360 M5


Internal



Yes


PCI Card form factor



Full-height (low-profile)


Product colour



Green


RoHS compliance



Yes


Network



Flow control support



Yes


iSCSI support



Yes


Jumbo frames



9600


Jumbo frames support



Yes


Maximum data transfer rate



40000 Mbit/s


Networking standards



IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1Qbg, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba


VLAN tagging



Yes


Operational conditions



Operating altitude



0 - 2133 m


Operating relative humidity (H-H)



20 - 80 %


Operating temperature (T-T)



0 - 55 �C


Other features



Flow control support



Yes


Jumbo frames



9600


Package dimensions



Gross Weight (Package, kg)



0.32 kg


Packaging data



Quantity



1


Ports & interfaces



Connectivity technology



Wired


Fiber ports quantity



2


Host interface



PCI Express


Interface



Fiber


PCI Card form factor



Full-height (low-profile)


Product dimensions



Net Weight (Product, kg)



0.22 kg


Sustainability



Sustainability certificates



RoHS


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


Lenovo


Warranty



1 Year(s)
