Lenovo 12N9GAT1EU Thinkcentre Tiny-In-One 22 12N9GAT1EU

One machine to connect you with the world.
Multitask with multiple devices.
The ThinkCentre Tiny-In-One (TIO) 22 Gen 5 Touch is an all-rounder with its 21,5-inch FHD In-Plane Switching panel which provides an immersive video calling experience. This Modular design of the monitor makes it compatible with Lenovo�s range of high-performance ThinkCentre and ThinkStation Tiny Computers from 4th Gen, and gives a complete working experience when paired with its VoIP features. This can be installed on your monitor effortlessly and housed on the back of the monitor in a dedicated slot, making your desk cable-free. The classic installation mechanism ensures you have
a consistent experience, allowing you to easily and quickly mount last-gen Tiny PCs on the monitor. Designed to be a powerful VoIP machine, this monitor is enhanced with features that make video conferencing a great experience. During online meetings, the 1080p RGB webcam and integrated noise-cancellation microphone produce exceptionally clear audio and video. TIO 22 Gen 5 also has a Smart Traffic Light indicator that alerts everyone in the vicinity to an ongoing meeting, letting you remain focused. If remaining focused and staying in the conversation is of importance to you, then
the two built-in 3W speakers ensure that the audio from meetings is always clear and crisp. Easily manage VoIP calls with one toggle to change the volume or mute the call using the dedicated VoIP buttons. Your privacy is in your hands with the ThinkShutter, which allows you to cover the camera when not in its use. Navigate any content on the screen with ease using its 10-point capacitive touch capability or pen1 support. Lenovo takes care of the environment with green packaging and optional CO2 offset service for zero to minimal carbon emission. In addition to Tiny PCs, this monitor can also be easily connected to other notebooks, towers using the HDMI and DP ports, and to other peripherals using the USB ports. With the ThinkColour software2, customize the screen�s attributes, create screen profiles, and easily switch between them as per your work preference. Protects your eyes from harmful blue light without any color distortion during long hours of screen time with the Natural Low Blue Light technology. The TIO 22 Gen 5 is the perfect option if you�re looking for a clean and clutter-free setup to maximize productivity and enjoy an efficient, all-in-one experience.

Design



Certification



EU Energy Label (D-class) ENERGY STAR� Certified EPEAT� Gold Registered TCO Certified 9.0 TCO edge 2.0 Volatile Organic Compound Certification RoHS compliant Eyesafe Display 2.0, T�V Low Blue Light (Hardware solution), T�V Rheinland Eye Comfort


Product colour



Black


Display



Anti-glare screen



Yes


Backlight type



W-LED


Colour depth



8 bit


Colour gamut



99 %


Contrast ratio (dynamic)



3000000:1


Contrast ratio (typical)



1000:1


Display brightness (typical)



250 cd/m�


Display diagonal



21.5 "


Display number of colours



16.7 million colours


Display resolution



1920 x 1080 Pixels


Display technology



LED


HD type



Full HD


Maximum refresh rate



60 Hz


Native aspect ratio



16:9


Panel type



IPS


Pixel density



102 ppi


Pixel pitch



0.248 x 0.248 mm


Response time



6 Millisecond


Response time (fast)



4 Millisecond


RGB colour space



sRGB


Screen shape



Flat


sRGB coverage (typical)



99 %


Touchscreen



Yes


Viewable size, horizontal



47.61 cm


Viewable size, vertical



26.78 cm


Viewing angle, horizontal



178 �


Viewing angle, vertical



178 �


Ergonomics



Cable lock slot



Yes


Cable management



Yes


Height adjustment



Yes


Height adjustment



15.5 cm


Panel mounting interface



100 x 100


Pivot



Yes


Pivot angle



-5 - 90 �


Swivel angle range



-45 - 45 �


Swivelling



Yes


Tilt angle range



-5 - 23.5 �


VESA mounting



Yes


Multimedia



Built-in camera



Yes


Built-in microphone



Yes


Built-in speaker(s)



Yes


Number of speakers



2


RMS rated power



6 Watt


Package dimensions



Depth (package,cm)



17.6 cm


Gross Weight (Package, kg)



7.8 kg


Height (package,cm)



42.2 cm


Width (package,cm)



56.8 cm


Packaging content



Cables included



AC


Power adapter included



Yes


Power cable length



1 m


Quick start guide



Yes


Stand included



Yes


Performance



AMD FreeSync



No


Compatible operating systems



Windows 10, Windows 11


Low Blue Light technology



Yes


NVIDIA G-SYNC



No


Ports & interfaces



Built-in USB hub



Yes


DisplayPort version



1.2


DisplayPorts quantity



1


HDMI



Yes


HDMI ports quantity



1


HDMI version



1.4


Number of upstream ports



1


Number of USB Type-B upstream ports quantity



1


USB hub version



3.2 Gen 1 (3.1 Gen 1)


USB Type-A downstream ports quantity



1


USB upstream port type



USB Type-B


Power



AC input frequency



50/60 Hz


AC input voltage



100 - 240 V


Power consumption (max)



33 Watt


Power consumption (off)



0.5 Watt


Power consumption (standby)



0.3 Watt


Power consumption (typical)



13.4 Watt


Power supply type



External


Product dimensions



Net Weight (Product, kg)



6 kg


Technical details



Warranty period



3 year(s)


Vendor information



Brand Name


Lenovo


Warranty



1 Year(s)


Weight & dimensions



Bezel width (bottom)



4.6 cm


Bezel width (side)



2 mm


Bezel width (top)



2 mm


Depth (with stand)



20.76 cm


Depth (without stand)



7.28 cm


Height (with stand)



51.23 cm


Height (without stand)



33.91 cm


Weight (with stand)



5.5 kg


Weight (without stand)



3.2 kg


Width (with stand)



48.93 cm


Width (without stand)



48.93 cm
