Lenovo 42D0501 Network Card Internal Fiber 42D0501

QLogic - 8Gb FC Single-port HBA for IBM System x
The QLogic 8 Gb Fiber Channel host bus adapters (HBAs) for IBM System x are part of a family of high-performance 8 Gb HBA solutions. These HBAs deliver exceptional performance, enabling small and medium businesses to experience unsurpassed robustness and reliability for a wide spectrum of server, storage, and SANs.

Designed For:System Storage DS3400; System x3100 M4; x3200 M2; x3250 M2; x3250 M3; x3250 M4; x3300 M4; x3350; x3400; x3450; x3500; x3550; x3550 M2; x3620 M3; x3630 M3; x3630 M4; x3650; x3650 M2; x3650 M4 HD; x3655; x3755; x3850 M2; x3950 M2; x3950 X5.

Design



Certification



UL, TUV, VCCI Class B ITE, BSMI CNS 13438 Class B, cUL, DHHS, EN 61000-3-2, EN55022, EN 61000-3-3, EN55024, UL 60950, ICES-003 Class B, AS/NZ 3548 Class B, FCC Part 15 B, MIC, CSA C22.2, EN 60950-1, EN 60825


Component for



Server


Internal



Yes


Product colour



Green


Logistics data



Harmonized System (HS) code



85176990


Network



Maximum data transfer rate



8704 Mbit/s


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 45 �C


Other features



Internal memory



1 MB


Package dimensions



Gross Weight (Package, kg)



0.26 kg


Ports & interfaces



Connectivity technology



Wired


Fiber ports quantity



1


Host interface



PCI Express


Interface



Fiber


PCI version



1.0


Product dimensions



Net Weight (Product, kg)



0.2 kg


Product Depth



16.8 cm


Product Height



6.5 cm


Product Width



2.5 cm


Vendor information



Brand Name


Lenovo


Warranty



1 Year(s)
