Lenovo 4XB7A17077-RFB ThinkSystem 2.5" 5300 960GB 4XB7A17077-RFB

The 5300 Entry SATA solid-state drives (SSDs) are new SSDs for ThinkSystem servers. The drives use Micron 96-layer 3D NAND flash memory technology with a SATA 6Gbps interface and provide an affordable solution for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.

Features



Component for



Server/workstation


Data transfer rate



6 Gbit/s


Hardware encryption



Yes


Harmonized System (HS) code



84717070


Hot-swap



Yes


Interface



Serial ATA III


Mean time between failures (MTBF)



3000000 Hour


Memory type



3D TLC NAND


NVMe



No


Random read (4KB)



95 IOPS


Random write (4KB)



35 IOPS


Read latency



175 �s


Read speed



540 MB/s


RoHS compliance



Yes


Security algorithms



256-bit AES


SSD capacity



960 GB


SSD form factor



2.5"


Write latency



100 �s


Write speed



520 MB/s


Logistics data



Harmonized System (HS) code



84717070


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 70 �C


Storage temperature (T-T)



-40 - 85 �C


Vibration resistance



3.13 G


Package dimensions



Depth (package,cm)



19 cm


Gross Weight (Package, kg)



0.19 kg


Height (package,cm)



6.3 cm


Width (package,cm)



13 cm


Power



Power consumption (read)



2.8 Watt


Power consumption (write)



3.4 Watt


Product dimensions



Net Weight (Product, kg)



0.18 kg


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


Lenovo


Warranty



1 Year(s)
