Lenovo 7X06A0P2EA Thinksystem Sr650 Server Rack 7X06A0P2EA

Future defined data center
Lenovo delivers cost-effective, reliable, and scalable solutions by combining industry-leading technology and the world�s best software-defined offerings with Lenovo ThinkShield, XClarity, and TruScale Infrastructure Services to manage the life cycle of your data center needs. ThinkSystem SR650 provides support for data analytics, hybrid cloud, hyperconverged infrastructure, video surveillance, high performance computing and much more.

Workload-optimized support
Intel� Optane� DC Persistent Memory delivers a new, flexible tier of memory designed specifically for data center workloads that offer an unprecedented combination of high capacity, affordability, and persistence. This technology will have a significant impact on real-world data center operations: reduction of restart times from minutes down to seconds, 1.2x virtual machine density, dramatically improved data replication with 14x lower latency and 14x higher IOPS, and greater security for persistent data built into hardware.*
* Based on Intel internal testing, August 2018.

Flexible storage
Lenovo AnyBay design features a choice of drive interface type in the same drive bay: SAS drives, SATA drives, or U.2 NVMe PCIe drives. Freedom to configure some of the bays with PCIe SSDs and still use the remaining bays for capacity SAS drives provides the ability to upgrade to more PCIe SSDs in the future as needed.

Empowering IT management
Lenovo XClarity Controller is the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks. Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95% versus manual operation. Running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.

Design



Chassis type



Rack (2U)


Product colour



Black, Metallic


Rack mounting



Yes


Rack rails



Yes


Redundant fans support



Yes


Graphics



Maximum graphics card memory



16 MB


On-board graphics card



Yes


On-board graphics card model



Matrox G200e


Memory



Internal memory



32 GB


Internal memory type



DDR4-SDRAM


Memory clock speed



2933 MHz


Memory layout (slots x size)



1 x 32 GB


Network



Cabling technology



10/100/1000Base-T(X)


Ethernet LAN



Yes


Operational conditions



Operating altitude



0 - 3050 m


Operating relative humidity (H-H)



8 - 90 %


Operating temperature (T-T)



5 - 45 �C


Storage relative humidity (H-H)



8 - 90 %


Storage temperature (T-T)



-40 - 60 �C


Package dimensions



Gross Weight (Package, kg)



1.29 kg


Performance



Performance management



XClarity Enterprise


Trusted Platform Module (TPM)



Yes


Ports & interfaces



USB 2.0 ports quantity



1


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



3


VGA (D-Sub) ports quantity



1


Power



Number of redundant power supplies installed



2


Power supply



750 Watt


Power supply input frequency



50 - 60 Hz


Redundant power supply (RPS) support



Yes


Processor



Embedded options available



No


Execute Disable Bit



Yes


Motherboard chipset



Intel� C624


Number of processors installed



1


Processor boost frequency



3.2 GHz


Processor cache



11 MB


Processor family



Intel Xeon Silver


Processor frequency



2.1 GHz


Processor generation



2nd Generation Intel� Xeon� Scalable


Processor manufacturer



Intel


Processor model



4208


Processor special features



Enhanced Intel SpeedStep Technology



Yes


Intel 64



Yes


Intel Trusted Execution Technology



Yes


Intel TSX-NI



Yes


Intel Virtualization Technology (VT-x)



Yes


Intel Virtualization Technology for Directed I/O (VT-d)



Yes


Intel VT-x with Extended Page Tables (EPT)



Yes


Product dimensions



Net Weight (Product, kg)



0.99 kg


Product Depth



76.4 cm


Product Height



8.7 cm


Product Width



44.5 cm


Storage



Optical drive type



No


RAID levels



0, 1, 5, 6, 10, 50, 60


RAID support



Yes


Supported RAID controllers



9350-8i


Vendor information



Brand Name


Lenovo


Warranty



1 Year(s)
