Lenovo 7ZT7A00546 DCG ThinkSystem 7ZT7A00546

The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.

ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.

The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.

Design



Certification



UL recognized to UL60950-1 2nd Edition FCC Rules, Part 15, Class A Australian EMC Framework (RCM) Japan VCCI, Class A Industry Canada, ICES-003, Class A EU (CE Mark) Korea KC-RRA, Class A


Chipset



Intel� C624


Compatible products



SR630 SR650 SR850 SR860 SR950


Internal



Yes


Product colour



Green, Metallic


RoHS compliance



Yes


Network



Ethernet LAN



Yes


Ethernet LAN data rates



10000


Flow control support



Yes


Jumbo frames



9728


Jumbo frames support



Yes


Maximum data transfer rate



10000 Mbit/s


Networking standards



IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x


Quality of Service (QoS) support



Yes


Security algorithms



SNMP


VLAN tagging



Yes


Other features



Chipset



Intel C624


Flow control support



Yes


Harmonized System (HS) code



85176990


Intel Data Direct I/O Technology



Yes


Intel Virtual Machine Device Queues (VMDq)



Yes


Jumbo frames



9728


Number of VLANs



4096


PCI-SIG* SR-IOV Capable



Yes


Receive Side Scaling (RSS)



Yes


Package dimensions



Depth (package,cm)



24.2 cm


Gross Weight (Package, kg)



0.245 kg


Height (package,cm)



5.6 cm


Width (package,cm)



15.1 cm


Ports & interfaces



Connectivity technology



Wired


Fiber ports quantity



2


Host interface



PCI Express


Interface



Fiber


Product dimensions



Net Weight (Product, kg)



0.2 kg


Sustainability



Sustainability certificates



RoHS


System requirements



Other operating systems supported



VMware vSphere ESXi


Server operating systems supported



SUSE Linux Enterprise Server 11, SUSE Linux Enterprise Server 12, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016


Technical details



Sustainability certificates



RoHS


Vendor information



Brand Name


Lenovo


Warranty



1 Year(s)
