LevelOne FCS-5092 FIXED DOME OUTDOOR CAMERA 5-MP FCS-5092

The LevelOne FCS-5092 is a fixed-position outdoor camera offering an ultra-reliable, cost-effective solution for outdoor IP surveillance networks, and is rated at IP67 to operate within rain, extreme heat, snow, dust and humid conditions. Offering clear, sharp imagery with 6-Megapixel resolution and the versatility of 802.3af standard PoE to transfer power and data via a single Cat.5 cable, the LevelOne FCS-5092 should be an essential part of any security deployment that requires smart, reliable outdoor cameras.

Audio



Audio system



1-way


Camera



Camera shutter speed



1/3 - 1/100000 Second


Field of view (FOV) angle



83.9 �


Design



Form factor



Bullet


International Protection (IP) code



IP67


LED indicators



Power


Mounting type



Wall


Product colour



White


Weatherproof



Yes


Image sensor



Optical sensor size



1/2.9 "


Progressive scan



Yes


Sensor type



CMOS


Lens system



Digital zoom



8 x


Focus adjustment



2.0


Number of lenses



1


Logistics data



Harmonized System (HS) code



85258900


Master (outer) case gross weight



15 kg


Master (outer) case height



46 cm


Master (outer) case length



40 cm


Master (outer) case width



49 cm


Products per master (outer) case



9 pc(s)


Management features



Reset button



Yes


Web-based management



Yes


Network



Bluetooth



No


Cabling technology



10/100Base-T(X)


Ethernet interface type



Fast Ethernet


Ethernet LAN



Yes


Live view



Yes


Networking standards



IEEE 802.3af


Number of users



16 user(s)


Quality of Service (QoS) support



Yes


Streaming method



Multicast


Supported network protocols



TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6


Wi-Fi



No


Night vision



LED type



IR


Night vision



Yes


Night vision distance



60 m


Operational conditions



Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



-30 - 60 �C


Storage temperature (T-T)



-30 - 60 �C


Other features



Browser supported



IE 10+, Chrome 57.0+, Firefox 52.0+


Package dimensions



Depth (package,cm)



16 cm


Gross Weight (Package, kg)



1.2 kg


Height (package,cm)



38 cm


Width (package,cm)



15.5 cm


Packaging content



Manual



Yes


Number of cameras



1


Resource CD



Yes


Screws included



Yes


Performance



Certification



FCC, UL


Connectivity technology



Wired


Day/night mode



Yes


Dynamic range



120 dB


Infrared (IR) cut-off filter



Yes


Number of languages



33


Placement supported



Indoor & outdoor


Plug and Play



Yes


Type



IP security camera


Wide Dynamic Range (WDR)



Yes


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Power



AC input voltage



12 V


Power consumption (max)



9 Watt


Power consumption (Power over Ethernet (PoE))



7.5 Watt


Power consumption (typical)



7 Watt


Power over Ethernet (PoE)



Yes


Power source type



PoE


Product dimensions



Net Weight (Product, kg)



1.0999999999999999 kg


Product Depth



15.5 cm


Product Height



15.6 cm


Product Width



38.6 cm


Security



Active tampering alarm



Yes


Digital watermark



Yes


Human and vehicle targets classification



Yes


Intelligent Video Surveillance (IVS) system features



Crossing line, Face detection, Human detection, Intrusion, Region entrance detection, Region exiting detection, Vehicle detection


IP address filtering



Yes


Storage



Built-in HDD



No


Card reader integrated



Yes


Compatible memory cards



MicroSDHC, MicroSDXC


Maximum memory card size



256 GB


System requirements



Mac operating systems supported



Y, Yes


Windows operating systems supported



Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64


Technical details



Master (outer) cases per pallet (air)



12 pc(s)


Pallet gross width



120 cm


Pallet height (air)



1260 cm


Removable IR-cut filter



Yes


Sustainability certificates



CE, RoHS


Sustainability compliance



Yes


Vendor information



Brand Name


LevelOne


Warranty



1 Year(s)


Video



Frame rate



60 fps


Image quality adjustment



Brightness, Contrast, Saturation, Sharpness


Maximum resolution



3200 x 1800 Pixels


Privacy masking



Yes


Supported graphics resolutions



640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520, 3200 x 1800


Total megapixels



6 MP


Video compression formats



H.264, H.265


Video formats supported



MPEG4
