LevelOne FGU-5021 50-Port-Fast Ethernet-Switch FGU-5021

- 10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX
- 9K jumbo frames to increase data transfer rates
- Supports 8K MAC address auto-learning and auto-aging
- 19-inch metal housing
- Quick and easy installation

Fast connections and fiber distances
FGU-5021 is a 48-port Fast Ethernet Switch (10/100 Mbps) that gives you a high-performance, low-cost, easy-to-use, solution to expand your network reach. With 2 Gigabit ports and 2 SFP Port , you�re able to connect to other networks for flexible and powerful deployment options.

Plug and Play, Flexible and Easy
GSW-5150 is plug-and-play so no configuration is required. Providing auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as general ports or Uplink ports, and any port can be simply plugged into a server, a hub, a router or a switch, using a straight cable or crossover cable. Diagnostic LEDs which display link status and activity, allowing you to quickly detect and correct problems on the network.

Data transmission



Jumbo frames



9000


Jumbo frames support



Yes


MAC address table



8000 entries


Packet buffer memory



4 MB


Store-and-forward



Yes


Switching capacity



13.6 Gbit/s


Design



Certification



CE/FCC


Housing material



Metal


LED indicators



Activity, Link, Power


Product colour



Grey


Rack mounting



Yes


Logistics data



Harmonized System (HS) code



85176990


Master (outer) case gross weight



13.8 kg


Master (outer) case height



53.5 cm


Master (outer) case length



39.5 cm


Master (outer) case width



52 cm


Products per master (outer) case



5 pc(s)


Network



10G support



No


Auto MDI/MDI-X



Yes


Auto-negotiation



Yes


Copper ethernet cabling technology



10BASE-T, 100BASE-T, 1000BASE-T, 1000BASE-TX


Full duplex



Yes


MAC address auto-aging supported



Yes


MAC address auto-learning supported



Yes


Networking standards



IEEE 802.3, IEEE 802.3az, IEEE 802.3u


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



5 - 90 %


Storage temperature (T-T)



-40 - 70 �C


Optical fiber



Fiber ethernet cabling technology



100BASE-X, 1000BASE-X


Package dimensions



Depth (package,cm)



10 cm


Gross Weight (Package, kg)



2.82 kg


Height (package,cm)



51 cm


Width (package,cm)



37.5 cm


Packaging data



Cables included



AC


Quick start guide



Yes


Performance



Harmonized System (HS) code



85176990


Internal memory



16 MB


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



50


Basic switching RJ-45 Ethernet ports type



Fast Ethernet (10/100)


Combo SFP ports quantity



2


Console port



RJ-45


Fast Ethernet (copper) ports quantity



48


Fiber optic connector



SFP


Gigabit Ethernet (copper) ports quantity



2


Installed SFP modules quantity



2


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Power consumption (typical)



28.6 Watt


Power supply included



Yes


Power over Ethernet (PoE)



Power over Ethernet (PoE)



No


Product dimensions



Net Weight (Product, kg)



2.7 kg


Product Depth



23 cm


Product Height



44 cm


Product Width



4.4 cm


Vendor information



Brand Name


LevelOne


Warranty



1 Year(s)
