Description
Product Overview
The FSW-1650 switch provides an ideal solution for small businesses that demand a reliable network switch that provides a high bandwidth interface between file servers and workgroups, departments and offices.
Advanced Networking Features
The LevelOne FSW-1650 is a wire-speed, nonblocking 16 port Fast Ethernet Unmanaged Switch with an internal power supply. It provides a network with an 8K MAC address table, 3.2Gbps backplane throughput, asymmetrical flow-control support for full-duplex network connectivity, auto-negotiation and Auto-MDIX.
The 16-port Fast Ethernet Switch utilizes packetstore- and forwarding switching for error-free data transmissions and IEEE802.3x backpressure flow control to control data flow between the sending and receiving nodes as well as to prevent any data packet loss.
Compact Design
The FSW-1650 is a compact designed network switch. Users can place the switch on any desktop area or mount it in a 19-inch server rack or cabinet by using the included rack-mounting accessory kit.
Quick Configuration and Easy Maintenance
The LevelOne FSW-1650 does not require any software configuration. It is Plug-and-Play enabled for quick set-up and immediate use within the Local Area Network. The 16 port Faster Ethernet Switch is equipped with a full range of LEDs for instant error detection, networking monitoring and network
troubleshooting.
- Provides flexibility of 16 x 10/100BASE-TX ports
- 10/100Mbps-Full/Half-duplex, Auto-Negotiation, Auto-MDI/MDIX
- Supports 8K MAC address auto-learning and auto-aging
- QoS control for traffic prioritization and bandwidth management
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- 19-inch metal housing
- Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
Data transmission
MAC address table
8192 entries
Store-and-forward
Yes
Switching capacity
3.2 Gbit/s
Design
Certification
CE RoHS
LED indicators
Activity, LAN, Link, Power
Product colour
Grey
Rack mounting
Yes
Stackable
No
Logistics data
Harmonized System (HS) code
85176990
Management features
Switch type
Unmanaged
Network
10G support
No
Cable types supported
Cat5
Copper ethernet cabling technology
10BASE-T, 100BASE-TX
Full duplex
Yes
Networking standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Operational conditions
Operating relative humidity (H-H)
10 - 90 %
Operating temperature (T-T)
0 - 40 �C
Storage relative humidity (H-H)
5 - 95 %
Storage temperature (T-T)
-40 - 70 �C
Package dimensions
Depth (package,cm)
9.4 cm
Gross Weight (Package, kg)
5.74 kg
Height (package,cm)
55 cm
Width (package,cm)
30.8 cm
Packaging data
Cables included
AC
Quick start guide
Yes
Wall mounting kit
Yes
Performance
Buffer size
160 KB
Harmonized System (HS) code
85176990
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
16
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Power
AC input frequency
50 - 60 Hz
AC input voltage
100 - 240 V
Power consumption (typical)
6.2 Watt
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Product dimensions
Net Weight (Product, kg)
4.65 kg
Product Depth
20.8 cm
Product Height
44 cm
Product Width
4.4 cm
Protocols
Switching protocols
CSMA/CD
Vendor information
Brand Name
LevelOne
Warranty
2 Year(s)
