LevelOne GEP-0523 5-Port Gigabit Poe Switch. GEP-0523
- UPC:
- 4015867207437
- MPN:
- GEP-0523
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
The LevelOne GEP-0523 is a Gigabit Ethernet PoE switch with a total of 5 ports, one of which is available as uplink port and 4 ports for Power over Ethernet. Per PoE port a power supply of up to 30W is possible. The total PoE power budget is 60W. It is an ideal solution when office and home users use a combination of PoE and non-PoE devices.
The GEP-0523\'s four PoE-enabled ports make it the ideal solution for office users using PoE-enabled devices in the workplace. This can include a mix of PoE IP phones, PoE Wifi APs and PoE IP cams. It is the perfect solution for offices that want to upgrade their office equipment and LAN infrastructure to PoE capability or upgrade with Gigabit performance. The switch automatically detects the connected IEEE 802.3at/af standard device and provides these devices with power and data over a single cable.
In addition, the GEP-0523 enables users to provide a stable and reliable high-speed LAN environment with store-and-forward switching architecture, packet error filtering and blockage-free packet forwarding. The 802.3x flow control mechanisms operate in both full and half duplex modes. This device supports the N-Way Auto Negotiation protocol, which automatically detects network speed and duplex mode.
For instant fault detection, the GEP-0523 is equipped with a full range of LEDs to help monitor and troubleshoot the network.
Data transmission
Jumbo frames
9126
Jumbo frames support
Yes
MAC address table
8000 entries
Maximum data transfer rate
1000 Gbit/s
Packet buffer memory
1 MB
Store-and-forward
Yes
Design
Certification
CE,FCC
Product colour
Black
Rack mounting
No
Logistics data
Harmonized System (HS) code
85176990
Management features
Traffic classification
Yes
Network
10G support
No
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Operational conditions
Operating relative humidity (H-H)
5 - 90 %
Operating temperature (T-T)
-20 - 70 °C
Storage relative humidity (H-H)
5 - 90 %
Storage temperature (T-T)
-20 - 70 °C
Package dimensions
Depth (package,cm)
5.5 cm
Gross Weight (Package, kg)
0.98 kg
Height (package,cm)
23 cm
Width (package,cm)
19 cm
Packaging data
AC adapter included
Yes
Quick start guide
Yes
Performance
Mean time between failures (MTBF)
30000 Hour
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power
DC input voltage
52 - 57 V
Input current
1.25 A
Power consumption (typical)
5 Watt
Power protection features
Over current, Short circuit
Power supply included
Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
4
Total Power over Ethernet (PoE) budget
60 Watt
Product dimensions
Net Weight (Product, kg)
0.75 kg
Product Depth
3 cm
Product Height
11.1 cm
Product Width
9.6 cm
Vendor information
Brand Name
LevelOne
Warranty
1 Year(s)
