LevelOne GEU-2431 X Ge GEU-2431 19\" Rack Mount GEU-2431

Gigabit Speeds: Take Your Data to the Next Level
GEU-2431 is a 24-port Gigabit Ethernet Switch that gives you a high-performance, low-cost, easy-to-use, seamless upgrade to boost your network to 1000Mbps. Increase the speed of your network backbone to a massive 48Gbps and bring lightning fast Gigabit connections to all your computers.

Bandwidth hungry? Not a problem.
What happens when you have several users accessing multimedia applications all at the same time? No need to worry as GEU-2431 allows you to move large files faster and easier. Transfer your CGI, CAD, video, or other large multimedia files over the network instantly and without lag.

Plug and Play, Flexible and Easy
GEU-2431 is plug-and-play so no configuration is required. Providing auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as general ports or Uplink ports, and any port can be simply plugged into a server, a hub, a router or a switch, using a straight cable or crossover cable.

Data transmission



Jumbo frames



9000


Jumbo frames support



Yes


MAC address table



8000 entries


Design



Certification



CE, RoHS


Form factor



1U


LED indicators



Y, Yes


Product colour



Black


Rack mounting



Yes


Stackable



No


Logistics data



Harmonized System (HS) code



85176990


Management features



Switch type



Unmanaged


Network



10G support



No


Auto MDI/MDI-X



Yes


Auto-negotiation



Yes


Copper ethernet cabling technology



10BASE-T, 100BASE-TX, 1000BASE-T


Ethernet LAN data rates



10, 100, 1000


Full duplex



Yes


Half duplex



Yes


Networking standards



IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x


Operational conditions



Operating relative humidity (H-H)



5 - 90 %


Operating temperature (T-T)



-10 - 55 �C


Storage relative humidity (H-H)



5 - 95 %


Storage temperature (T-T)



-40 - 75 �C


Package dimensions



Depth (package,cm)



49.7 cm


Gross Weight (Package, kg)



2.74 kg


Height (package,cm)



9.3 cm


Width (package,cm)



21.8 cm


Packaging data



Cables included



AC


Quick start guide



Yes


Rack mount kit



Yes


Performance



Built-in processor



Yes


Internal memory



4.1 MB


Processor frequency



500 MHz


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



24


Basic switching RJ-45 Ethernet ports type



Gigabit Ethernet (10/100/1000)


Gigabit Ethernet (copper) ports quantity



24


Power connector



AC-in jack


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Input current



1 A


Power consumption (typical)



25 Watt


Power source



AC


Power supply included



Yes


Power over Ethernet (PoE)



Power over Ethernet (PoE)



No


Product dimensions



Net Weight (Product, kg)



2.11 kg


Product Depth



14 cm


Product Height



4.5 cm


Product Width



43.8 cm


Vendor information



Brand Name


LevelOne


Warranty



1 Year(s)
