Levelone
LevelOne IGP-0802 8-Port Gigabit PoE Ind. Switch IGP-0802
- UPC:
- 4015867196656
- MPN:
- IGP-0802
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
The LevelOne IGP-0802 is 10/100/1000M industrial 8 port high power POE switch is equipped with 8 port 30Watts PSE. It is designed for 48-56VDC input sources, especially for IP surveillance, traffic monitoring and for a broad range of applications. It can be used as a stand-alone device for buses, trucks, and other vehicles for Surveillance purposes. It is being rigorously tested for your Security, Transportation and Telco application.
Key Features
- PoE ports can support the IEEE 802.3at standard and power up 30W devices
- 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX
- 40°C to 75°C operating temperature range
- Provides DIN-rail, wall or desktop mounting
- IP30 metal case
- Redundant power inputs with Terminal Block
Data transmission
Jumbo frames
9000
Jumbo frames support
Yes
MAC address table
8000 entries
Store-and-forward
Yes
Switching capacity
16 Gbit/s
Design
Certification
FCC,CE,VCCI
DIN rail mounting
Yes
Housing material
Metal
International Protection (IP) code
IP30
LED indicators
PoE, Power
Product colour
Black
Safety
EN60950-1, EN60068
Wall mountable
Yes
Logistics data
Master (outer) case gross weight
12.6 kg
Master (outer) case height
57 cm
Master (outer) case length
24 cm
Master (outer) case width
35 cm
Products per master (outer) case
16 pc(s)
Management features
Switch type
Unmanaged
Network
Auto MDI/MDI-X
Yes
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex
Yes
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Operational conditions
Operating relative humidity (H-H)
5 - 95 %
Operating temperature (T-T)
-40 - 75 °C
Other features
Terminal block port
Yes
Package dimensions
Depth (package,cm)
6.5 cm
Gross Weight (Package, kg)
0.73 kg
Height (package,cm)
21.5 cm
Width (package,cm)
16.5 cm
Packaging data
Manual
Yes
Terminal block included
Yes
Wall mounting kit
Yes
Performance
Harmonized System (HS) code
85176990
Mean time between failures (MTBF)
510304 Hour
Plug and Play
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power
DC input voltage
48 - 56 V
Redundant power supply (RPS) support
Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) power per port
36 Watt
Power over Ethernet (PoE) voltage range
48 - 56 V
Power over Ethernet plus (PoE+) ports quantity
8
Total Power over Ethernet (PoE) budget
200 Watt
Product dimensions
Net Weight (Product, kg)
0.525 kg
Product Depth
3.62 cm
Product Height
14.2 cm
Product Width
10.5 cm
Vendor information
Brand Name
LevelOne
Warranty
1 Year(s)
