Lindy 43380 5m USB 3.2 Gen 1 C/A Active 43380

The Lindy USB 3.2 Gen 1 C/A Active Extension Cable Pro is a high performance active cable that allows access to USB peripherals over long distances. With support for data transfer speeds of up to 5Gbps this extension cable is perfect for transferring large data volumes quickly and reliably.

This 5m USB 3.2 C/A Active Extension Cable can be used standalone or as part of the Lindy USB 3.0 Active Extension System Pro. This system is a modular solution that can combine multiple USB Active Extension Pro cables and a USB 3.0 Active Extension Pro hub to distribute USB signals to up to 4 devices at about 40m (depending on the cable configurations used).

Please note that only the USB 3.2 C/A Active Extension Pro 5m (Nr. 43380) or the 8m version (Nr. 43381) can be connected directly to your computer. Once the first cable has been connected, you can then cascade further cables to achieve a maximum distance of 40m. The final part of the extension can be any segment of the Extension Pro System (Nr. 43157, 43158, 43229, 43361). If you need to extend multiple devices or if you connect a USB device with high power requirement, then you should use the 10m Hub Pro unit (Nr. 43159) with it_ s power supply as the final part of the extension.

If a USB Type C device is to be connected, a USB 3.0 Active Extension Type A to C (no. 43375 or 43376) can also be used as the last segment.

This cable features industry-proven active technology and locking connectors to ensure full signal integrity in the most demanding environments.

Information about USB 3.0, 3.1 & 3.2

USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.

USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps.

USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.

Features



AWG wire size



28/28/24


Cable jacket material



Polyvinyl chloride (PVC)


Cable length



5 m


Cable type



Round cable


Certification



California Proposition 65


Conductor material



Tinned copper


Connector 1



USB C


Connector 1 form factor



Straight


Connector 1 gender



Male


Connector 2



USB A


Connector 2 form factor



Straight


Connector 2 gender



Female


Connector contacts plating



Gold


Connector housing material



Plastic


Connector material



Nickel


Connector shield material



Aluminium


Connector shielding



Yes


Contact material



Brass


Product colour



Black


Transmission medium



Twisted pair


USB version



USB 3.2 Gen 1 (3.1 Gen 1)


Operational conditions



Operating temperature (T-T)



0 - 50 �C


Storage temperature (T-T)



-20 - 60 �C


Package dimensions



Depth (package,cm)



7 cm


Gross Weight (Package, kg)



0.26 kg


Height (package,cm)



20 cm


Width (package,cm)



24 cm


Packaging content



Manual



Yes


Packaging data



Quantity per pack



1 pc(s)


Power



Power note



2.5/0.7mm DC


Product dimensions



Net Weight (Product, kg)



0.2 kg


Sustainability



Sustainability certificates



CE, Federal Communications Commission (FCC), REACH, RoHS


Sustainability compliance



Yes


Technical details



Warranty period



2 year(s)


Vendor information



Brand Name


Lindy


Warranty



2 Year(s)


Weight & dimensions



Bend radius (min)



5.5 cm


Cable diameter



5 mm


Connector 1 dimensions (WxDxH)



12.4 x 39.7 x 9 mm


Connector 2 dimensions (WxDxH)



20 x 80 x 13 mm
