Mean Well APC-16-350 Power Supply Unit 16.8 W White APC-16-350

- Constant current mode design
- Universal AC input / Full range
- Protections:Short circuit / Over voltage
- Fully isolated plastic case
- Small and compact size
- Cooling by free air convection
- Class power unit, no FG
- Class 2 power unit
- Pass LPS
- IP42 design
- Suitable for LED lighting and moving sign applications
- 100% full load burn-in test
- Low cost / High reliability

Design



Illumination



No


LED indicators



N, No


Product colour



White


Logistics data



Master (outer) case net weight



14 kg


Products per master (outer) case



120 pc(s)


Operational conditions



Operating relative humidity (H-H)



20 - 90 %


Operating temperature (T-T)



-30 - 70 �C


Storage relative humidity (H-H)



10 - 95 %


Storage temperature (T-T)



-40 - 80 �C


Other features



Electromagnetic compatibility



EN55022, EN61000-3-2 Class A, EN61000-3-3


Rise time



200 Millisecond


Voltage tolerance



5 %


Package dimensions



Gross Weight (Package, kg)



0.65 kg


Performance



Mean time between failures (MTBF)



1145700 Hour


Safety



UL8750, CSA C22.2 No.250.0-08, EN60950-1


Power



AC input frequency



47 - 63 Hz


AC input voltage



90 - 264 V


Efficiency



84 %


Hold time



12 Millisecond


Input current



0.3 - 0.5 A


Power protection features



Over voltage, Short circuit


Total power



16.8 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



7.7 cm


Product Height



2.9 cm


Product Width



4 cm


Vendor information



Brand Name


Mean Well


Warranty



1 Year(s)
