Mean Well LRS-150-24 Power Supply Unit 156 W LRS-150-24

- AC input range selectable by switch
- Withstand 300VAC surge input for 5 second
- No load power consumption<0.5W
- Miniature size and 1U low profile
- High operating temperature up to 70�C
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- Compliance to IEC/EN 60335-1(PD3) and
- IEC/EN61558-1, 2-16 for household appliances
- Operating altitude up to 5000 meters
- Withstand 5G vibration test
- High efficiency, long life and high reliability
- LED indicator for power on
- Over voltage category III
- 100% full load burn-in test

Design



LED indicators



Y, Yes


Product colour



Metallic


Operational conditions



Operating relative humidity (H-H)



20 - 90 %


Operating temperature (T-T)



-30 - 70 �C


Storage relative humidity (H-H)



10 - 95 %


Storage temperature (T-T)



-40 - 85 �C


Other features



Rise time



500 Millisecond


Package dimensions



Gross Weight (Package, kg)



0.65 kg


Performance



Mean time between failures (MTBF)



601000 Hour


Safety



UL60950-1, TUV EN60950-1, EN60335-1, EN61558-1 /- 2 - 16


Power



AC input frequency



47 - 63 Hz


AC input voltage



85 - 132 V


Efficiency



89 %


Hold time



40 Millisecond


Input current



3/115VC, 1.7/230VC A


Power protection features



Over voltage, Overheating, Overload


Total power



156 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



15.9 cm


Product Height



3 cm


Product Width



9.7 cm


Vendor information



Brand Name


Mean Well


Warranty



1 Year(s)
