Mean Well
Mean Well SDR-120-12 Stromversorgung Power Supply SDR-120-12
(No reviews yet)
Write a Review
- UPC:
- 0000000000000
- MPN:
- SDR-120-12
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
High efficiency 91% & low dissipation
150% peak load capability
Built-in active PFC, PF>0.93
Installable on DIN rail TS-35/7.5 or 15
Built-in DC OK relay contact
100% full load burn-in test
Design
Product colour
Metallic
Operational conditions
Operating relative humidity (H-H)
20 - 95 %
Operating temperature (T-T)
-25 - 70 �C
Storage temperature (T-T)
-40 - 85 �C
Other features
Rise time
60 Millisecond
Package dimensions
Gross Weight (Package, kg)
0.65 kg
Performance
Mean time between failures (MTBF)
289900 Hour
Safety
EN60950-1, UL508
Power
AC input frequency
47 - 63 Hz
AC input voltage
88 - 264 V
Efficiency
89 %
Hold time
20 Millisecond
Peak power
180 Watt
Power factor
0.93
Power Factor Correction (PFC) type
Active
Power protection features
Over voltage, Overheating, Overload, Short circuit
Total power
120 Watt
Product dimensions
Net Weight (Product, kg)
0.5 kg
Product Depth
11.35 cm
Product Height
12.52 cm
Product Width
4 cm
Vendor information
Brand Name
Mean Well
Warranty
1 Year(s)
View AllClose
150% peak load capability
Built-in active PFC, PF>0.93
Installable on DIN rail TS-35/7.5 or 15
Built-in DC OK relay contact
100% full load burn-in test
Design
Product colour
Metallic
Operational conditions
Operating relative humidity (H-H)
20 - 95 %
Operating temperature (T-T)
-25 - 70 �C
Storage temperature (T-T)
-40 - 85 �C
Other features
Rise time
60 Millisecond
Package dimensions
Gross Weight (Package, kg)
0.65 kg
Performance
Mean time between failures (MTBF)
289900 Hour
Safety
EN60950-1, UL508
Power
AC input frequency
47 - 63 Hz
AC input voltage
88 - 264 V
Efficiency
89 %
Hold time
20 Millisecond
Peak power
180 Watt
Power factor
0.93
Power Factor Correction (PFC) type
Active
Power protection features
Over voltage, Overheating, Overload, Short circuit
Total power
120 Watt
Product dimensions
Net Weight (Product, kg)
0.5 kg
Product Depth
11.35 cm
Product Height
12.52 cm
Product Width
4 cm
Vendor information
Brand Name
Mean Well
Warranty
1 Year(s)
Additional Information
Shipping: |
Available to Order - Call for ETA |
Delivery: |
Available to Order - Call for ETA |
