Mean Well SDR-960-48 Stromversorgung Power Supply SDR-960-48
- UPC:
- 0000000000000
- MPN:
- SDR-960-48
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
AC input 180~264VAC only
- 130% peak load capability
- 110mm slim design
- Built-in active PFC function compliance to EN61000-3-2
- High efficiency 94% and low power dissipation
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Cooling by free air convection
- Built-in constant current limiting circuit
- Can be installed on DIN rail TS-35/7.5 or 15
- UL508(industrial control equipment)approved
- EN61000-6-2(EN50082-2) industrial immunity level
- Current sharing up to 3840W(3+1)
- Built-in DC OK relay contact
- 100% full load burn-in test
Design
Product colour
Metallic
Operational conditions
Operating relative humidity (H-H)
20 - 95 %
Operating temperature (T-T)
-30 - 70 �C
Storage temperature (T-T)
-40 - 85 �C
Other features
Rise time
100 Millisecond
Package dimensions
Gross Weight (Package, kg)
0.65 kg
Performance
Mean time between failures (MTBF)
69800 Hour
Safety
EN60950-1, UL508
Power
AC input frequency
47 - 63 Hz
AC input voltage
180 - 264 V
Efficiency
94 %
Hold time
14 Millisecond
Peak power
1248 Watt
Power factor
0.95
Power Factor Correction (PFC) type
Active
Power protection features
Over voltage, Overheating, Overload, Short circuit
Total power
960 Watt
Product dimensions
Net Weight (Product, kg)
0.5 kg
Product Depth
15 cm
Product Height
12.52 cm
Product Width
11 cm
Vendor information
Brand Name
Mean Well
Warranty
1 Year(s)
