MikroTik XQ+31LC10D XQ+31LC10D XQ+31LC10D

The MikroTik 100 Gigabit product line keeps growing!
Add this QSFP module for distances up to 10 kilometers to your CCR2216, CRS504 or CRS518 setups and enjoy real speed and ultimate reliability. This optical module offers four independent full-duplex channels with up to 25 Gbps per channel bandwidth and an aggregate bandwidth of 100 Gbps.

The module has built-in digital diagnostic functions such as optical power, transceiver supply voltage, temperature, laser bias current monitoring, and other key parameter monitoring. These options can be helpful not only to alert the user during abnormal transceiver activity but also if specific customizable operating limits are exceeded. Monitoring allows you to plan ahead, make informed decisions and predict necessary upgrades or maintenance based on the transceiver performance.

Operational conditions



Maximum operating temperature



70 �C


Operating temperature (T-T)



0 - 70 �C


Package dimensions



Depth (package,cm)



3 cm


Gross Weight (Package, kg)



0.11 kg


Height (package,cm)



29 cm


Width (package,cm)



18.5 cm


Packaging data



Number of products included



1 pc(s)


Performance



Fiber optic connector



LC (UPC)


Interface type



QSFP28


Maximum data transfer rate



100000 Mbit/s


Maximum transfer distance



10000 m


Multi-mode fiber (MMF) supported



No


SFP transceiver type



Fiber optic


Single-mode fiber (SMF) supported



Yes


Wavelength



1309 nm


Power



Power consumption (typical)



4.5 Watt


Product dimensions



Net Weight (Product, kg)



0.04 kg


Vendor information



Brand Name


MikroTik


Warranty



15 Month(s)
