Moxa 40769 INDUSTRIAL UNMANAGED ETHERNETS 40769

5 and 8-port unmanaged Ethernet switches.
The EDS-305/308 are 5-port and 8-port Ethernet switches that provide an economical solution for your industrial Ethernet connections. The built-in relay warning function alerts network engineers when power failures or port breaks occur, and the switches are designed for harsh industrial environments, such as in hazardous locations (Class I, Div. 2/ATEX). The switches comply with FCC, T�V, UL, and CE standards, and come in two model types. Standard operating temperature range models (0 to 60�C) and wide operating temperature range models (-40 to 75�C). Both models undergo a 100% burn-in test to ensure that they fulfill the special needs of industrial automation control applications. The EDS-305/308 switches can be installed easily on a DIN-Rail or in a distribution box.
- Redundant dual 24 VDC power inputs.
- Relay output warning for power failure and port break alarm.
- Broadcast storm protection.
- Transparent transmission of VLAN tagged packets.
- 40 to 75?C operating temperature range (T models).

Data transmission



MAC address table



1000 entries


Maximum data transfer rate



0.1 Gbit/s


Store-and-forward



Yes


Supported data transfer rates



10/100 Mbps


Switching capacity



0.1 Gbit/s


Design



Stackable



Yes


Management features



Switch type



Unmanaged


Network



10G support



No


Auto MDI/MDI-X



Yes


Flow control support



Yes


Full duplex



Yes


Networking standards



IEEE 802.3, IEEE 802.3u, IEEE 802.3x


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 60 �C


Storage temperature (T-T)



-40 - 85 �C


Optical fiber



Fiber type



Multi-mode


Link budget



12 dB


RX sensitivity



-32 dB


Wavelength



1300 nm


Other features



Dimensions (WxDxH)



53.6 x 105 x 135 mm


Networking features



Fast Ethernet


Package dimensions



Depth (package,cm)



17 cm


Gross Weight (Package, kg)



1 kg


Height (package,cm)



9.5 cm


Width (package,cm)



20 cm


Performance



Mean time between failures (MTBF)



422000 Hour


Ports & interfaces



Basic switching RJ-45 Ethernet ports quantity



5


Fiber optic connector



ST


Fiber ports quantity



1


Power connector



DC-in jack


Power



Input current



0.13 A


Input voltage



12 - 48 V


Power source



AC/DC


Power over Ethernet (PoE)



Power over Ethernet (PoE)



No


Product dimensions



Net Weight (Product, kg)



0.9 kg


Vendor information



Brand Name


Moxa


Warranty



2 Year(s)
