MSI 306-7G03R21-809 Mag forge 100R Mid Tower 306-7G03R21-809

OPTIMIZED AIR FLOW
Two 120mm fans aligned vertically on the front to draw in air evenly across the entire face of the enclosure. That will contribute to positive air pressure within the case, the rising warm air will always be exhausted with the rear and top airflow from the MAG Forge 100 Series.

READY FOR OPTIMIZED MOTHERBOARD
Designed with multiple easy installation mechanisms and accommodated an up to ATX motherboard to provide an unhindered building experience.

TOOL-LESS TEMPERED GLASS
The light gray tone of 4mm tempered glass side panel is ideal for displaying RGB lighting effects and provides clear internal component construction.

The Forge 100 Series� thoughtful case design allows users to install/remove the tempered glass easily. Simply place the tempered glass on the stump of the case before installing it for a safe and simple process.

PERSONALIZE YOUR GAMING RIG
ustomizing Addressable RGB LEDs integrated in the front, top & rear cover with a dedicated control button; or with MSI Mystic Light software, MAG Forge 100R can cast millions of colors and effects that can be synchronized with a vast ecosystem of components to augment your build.

1 to 6 ARGB LED Control Board
User can intuitively control & switch 9 lighting effects through the LED switch button.

LED Switch Button
Keep pressing the LED button for three seconds, and then users can control the lighting effects via syncing with the motherboard by MSI mystic light app.

Cooling



Front fans diameters supported



120, 140


Front fans installed



2x 120 mm


Front fans supported description



addressable RGB LED


Number of front fans supported (max)



3


Number of rear fans supported (max)



1


Number of top fans supported (max)



2


Rear fans diameters supported



120


Rear fans installed



1x 120 mm


Top fans diameters supported



120, 140


Design



Anti-dust filter



Yes


Form factor



Midi Tower


Illumination



Yes


Illumination colour



Multi


Illumination location



Case fans


LED indicators



Y, Yes


Material



Tempered glass


Maximum CPU cooler height



16 cm


Maximum graphics card length



33 cm


Maximum PSU length



20 cm


Number of 2.5" bays



3


Number of 3.5" bays



2


Number of expansion slots



7


Number of internal 3.5" bays



2


On/off button



Yes


Product colour



Black, Transparent


Reset button



Yes


Side window



Yes


Suitable for



Gaming


Supported motherboard form factors



ATX, micro ATX, Mini-ITX


Tempered glass panel(s)



Yes


Type



PC


Logistics data



Harmonized System (HS) code



84733080


Package dimensions



Gross Weight (Package, kg)



7.33 kg


Ports & interfaces



Audio input



Y


Audio output



Y


USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity



2


Power supply



Power supply included



No


Power supply location



Bottom


Product dimensions



Net Weight (Product, kg)



5.64 kg


Product Depth



42.1 cm


Product Height



49.9 cm


Product Width



21 cm


Storage



HDD/SSD combo cage



Yes


Supported HDD sizes



2.5, 3.5


Vendor information



Brand Name


MSI


Warranty



1 Year(s)
