MSI Cubi NUC 1M Intel Core 3 100U Desktop PC NUC SFF Mini Computer HTPC 8GB RAM CUBI NUC 1M I3 100U FS 8GB 512GB W11P

Cubi NUC 1M: The Sustainable & Energy Efficient Mini-PC

The MSI Cubi NUC 1M is a small yet powerful mini-desktop with an incredibly compact 0.826L design suitable for commercial office work or use as home-theatre/entertainment PC (supports UHD/4K 60Hz display output & quadruple-monitor setups).

The Cubi NUC 1M i3 100U FS 8GB 512GB W11P configuration is a complete system equipped with an Intel- Core 3 processor 100U, 8 GB of DDR5-5200MHz memory, 512 GB of M.2 SSD storage, Intel Wi-Fi AX211 & Bluetooth 5.3 connectivity, as well as Windows 11 Pro software pre-installed.

The easy-to-upgrade SFF case can house both M.2 (1 x 2280, 1x 2242) & 2.5-inch storage, as well as up to 64 GB of system memory (2 x DDR5 SO-DIMM slots), and is VESA-mountable for a cleaner desktop.

Made with PCR (Post-consumer Recycled) plastic materials and recycled molded pulp tray packing design.

Front I/O connectivity includes a Mic-in/Headphone-out combo jack, 2x USB 10Gbps Type A and1x Micro-SD card Reader. The rear I/O features dual 2.5Gbps ethernet LAN ports, 2x Thunderbolt 4, 2 x HDMI 2.1 and 2x USB 10Gbps Type A

Features


INTEL MINI PC - The Cubi NUC 1M is a palm-sized mini PC featuring an Intel- Core 3 processor 100U CPU, 8GB DDR5 , 512GB M.2 SSD Storage, Windows 11 Pro software pre-installed


8GB RAM, UHD GRAPHICS - The system includes 8GB of pre-installed DDR5-5200 memory (1 x SO-DIMM slots) and supports 8K UHD display - ideal for watching movies; Thunderbolt 4 and HDMI 2.1 support quadruple monitor setups


512GB of pre-installed M.2 SSD storage ensures faster loading speeds 1x M.2 2280 SSD (PCIE, factory pre-installed), 1 x 2.5" HDD/SSD & and 1x M.2 2242 SSD free-slot


VESA mountable design and Mounting Bracket included (75mm x 75mm or 100mm x 100mm)


The front I/O panel features a 2x USB 10Gbps Type A and Micros-SD card reader; The rear I/O panel features 2x USB 10Gbps Type A as well. The compact 0.826L SFF case incorporates an efficient thermal design & low-noise fan with 21 dBA noise levels


WI-FI 6E AX211 & BLUETOOTH 5.3 - Network connectivity includes an Intel WI-FI 6E AX211 and dual 2.5G ethernet LAN ports


dTPM 2.0 (discrete Trusted Platform Module) hardware technology provides security for storing sensitive data & passwords



Processor


Processor base power
W


Processor cache
MB


Performance cores

2


Performance-core Max Turbo Frequency

4.7 GHz


Performance-core base frequency

1.2 GHz


Maximum turbo power

55 W


Efficient cores

4


Processor family

Intel Core 3


Efficient-core Max Turbo Frequency

3.3 GHz


Efficient-core base frequency

0.9 GHz


Processor generation

Intel Core (Series 1)


Number of processors installed

1


Processor model
0U


Processor threads

8


Processor manufacturer

Intel


Processor cores

6



Memory


Internal memory type

DDR5-SDRAM


Memory clock speed

5200 MHz


Memory slots

2x SO-DIMM


Internal memory

8 GB


Memory layout (slots x size)

1 x 8 GB


Maximum internal memory

64 GB



Other features


Locale

English


Built-in microphone

No


TV tuner integrated

No


Warranty period

3 year(s)



Ports & interfaces


Number of front audio ports

1


Intel- Thunderbolt 4

Yes


Number of rear USB ports

4


Thunderbolt 4 ports quantity

2


HDMI ports quantity

2


USB 3?2 Gen 1 (3?1 Gen 1) Type-A ports quantity

4


PowerShare

No


Microphone in

No


USB Type-C DisplayPort Alternate Mode

Yes


Line-out

No


Ethernet LAN (RJ-45) ports

2


S/PDIF out port

No


DVI port

No


HDMI version

1.4/2.1


DC-in jack

Yes


Fiber NIC port (Flex I/O)

No


Combo headphone/mic port

Yes


Line-in

No


Number of front USB ports

2



Graphics


On-board graphics card family

Intel- UHD Graphics


On-board graphics card

Yes


On-board graphics card model

Intel- UHD Graphics


On-board GPU manufacturer

Intel


Discrete graphics card

No


Discrete graphics card model

Not available



Design


Chassis type

Mini PC


Cable lock slot type

Kensington


VESA mounting

Yes


Cable lock slot

Yes


Colour name

Black


Introduction year
24


Country of origin

China


Placement supported

Horizontal


Volume

0.84 L


Product colour

Black


Housing material

Plastic


Introduction month

July



Storage


Storage media

SSD


M?2 SSD size

2280 (22 x 80 mm)


NVMe

Yes


HDD size

2.5"


Card reader integrated

Yes


SSD interface

M.2


Optical drive type

No


SSD capacity

512 GB


SSD form factor

M.2


Number of storage drives supported

3


Compatible memory cards

MicroSD (TransFlash)


Number of storage drives installed

1


Total storage capacity

512 GB


Number of SSDs installed

1



Weight & dimensions


Package height

94 mm


Package depth

220 mm


Package width
5 mm


Package weight

1.45 g


Height

50.1 mm


Width
2.5 mm


Depth
5.6 mm


Weight

0.625 g



Packaging content


Cables included

AC, Power


VESA mount included

Yes


Keyboard included

No


Display included

No


Mouse included

No


Screws included

Yes



Network


Wake-on-LAN ready

Yes


LAN controller

Intel I226-V


Wi-Fi standards

Wi-Fi 6E (802.11ax)


Bluetooth

Yes


Wi-Fi

Yes


Top Wi-Fi standard

Wi-Fi 6E (802.11ax)


WLAN controller manufacturer

Intel


Ethernet LAN

Yes


WLAN controller model

Intel Wi-Fi 6E AX211


Bluetooth version

5.3



Software


Operating system installed

Windows 11 Pro



Performance


Motherboard chipset

Intel SoC


Powered by

MSI


Product type

Mini PC


Trusted Platform Module (TPM)

Yes


Market positioning

Business


Trusted Platform Module (TPM) version

2.0


Motherboard form factor

NUC



Power


Power supply input frequency

50-60 Hz


Power supply input voltage
0-240 V


Power supply
0 W
