Msi MAG Z890 TOMAHAWK WIFI Socket 1851/Z890/Ddr5/S-Ata 6Gb/S/Atx MAG Z890 TOMAHAWK WIFI

Product Group:

Motherboards



Manufacturer:

MSI



SKU:
5659


Product Specifications



Product Name:

MSI MAG Z890 TOMAHAWK WIFI (Socket 1851/Z890/DDR5/S-ATA 6Gb/s/ATX)



Web Address:

uk.msi.com



Model Number:

MAG Z890 TOMAHAWK WIFI



EAN:

4711377259712



UPC:

824142382226



Package Type:

Retail



Warranty:

3 Years



Chipset:

Intel Z890



CPU Interface:

Socket 1851



CPU Support:

https://www.msi.com/Motherboard/MAG-Z890-TOMAHAWK-WIFI/support#cpu



RAM Technology:

DDR5 (Dual Channel)



RAM Slots:

4 x 288-pin



RAM Speeds:

Up to DDR5 9200 (O.C.)



Max. Memory Support:

256GB



PCI Express 4.0 x16:

2



PCI Express 5.0 x16:

1



S-ATA 6Gb/s Port(s):

4



M.2 Socket(s):

1 x PCIe Gen 5.0 x4
2 x PCIe Gen 4.0 x4
1 x PCIe Gen 4.0 x4/SATA



On-Board LAN:

Intel® Killer E5000 5Gbps LAN



Wireless NIC:

Wi-Fi 7



Wireless Technology:

Intel Killer BE1750x



Bluetooth:

v5.4



On-Board Audio:

Realtek ALC1220P Codec
7.1-Channel High Definition Audio
Supports S/PDIF output



On-Board Video:

Processor with integrated graphics is required



Back USB 5Gbps Port(s) Type-A:

4



Back USB 10Gbps Port(s) Type-A:

3



Back USB 10Gbps Port(s) Type-C:

1



Back USB 40Gbps Port(s) Type-C:

2



Back HDMI Port(s):

1



Back LAN Port(s):

1



Back Audio Jack(s):

2



Back S/PDIF Output Port(s):

1



Back Other Port(s):

Wi-Fi / Bluetooth



Back Button(s):

Flash BIOS
Clear CMOS



24-pin ATX Power:

1



8-pin ATX Power:

2



PCIe Power Connector(s):

1 x 8-pin



USB 2.0 Header(s):

4



USB 5Gbps Header(s):

2



USB 20Gbps Header(s):

1



Thunderbolt AIC Connector(s):

1



Front Panel Audio Connector:

1



TPM Header(s):

1



Internal Other Port(s):

3 x Addressable V2 RGB LED connector
1 x RGB LED connector
4 x EZ Debug LED
1 x EZ Digit Debug LED



Form Factor:

Standard ATX



Product Width:

243.84mm



Product Length:

304.08mm



Package Width:

27cm



Package Length:

34.5cm



Package Height:

7cm



Gross Weight:

2.10Kg



Special Features:

Support Intel Core Ultra Processors (Series 2) for LGA 1851 socket.
Supports DDR5 Memory, Dual Channel DDR5 9200+ MT/s (OC).
Ultra Performance: 16+1+1+1 Duet Rail Power System 90A SPS, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB made by 2oz thickened copper and server-grade level material.
Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience.
EZ DIY: EZ PCIe Release, EZ M.2 Shield Frozr II, EZ M.2 Clip II and EZ Antenna.
Lightning-Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2.
Ultra Connect: Thunderbolt 4 port, Intel Killer 5G LAN and Intel Killer Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission.
Audio Boost 4: Reward your ears with studio grade sound quality for the most immersive gaming experience.



Package Contents:

Motherboard
Quick Installation Guide
2 x SATA Cables
EZ M.2 Clips II
EZ M.2 Clip II Remover
USB Drive
Cable Sticker
EZ Wi-Fi Antenna
1 to 3 EZ Conn-Cable
EZ Front Panel Cable
