Msi PRO B760-P WIFI DDR4 Socket 1700/B760/Ddr4/S-Ata 6Gb/S/Atx PRO B760-P WIFI DDR4

MSI 1700 PRO B760-P WIFI DDR4
SKU: 122849
Product Group:Motherboards
Manufacturer:MSI
SKU:122849
Product Name:MSI PRO B760-P WIFI DDR4 (Socket 1700/B760/DDR4/S-ATA 6Gb/s/ATX)
Web Address:uk.msi.com
Model Number:PRO B760-P WIFI DDR4
EAN:4711377028363
UPC:824142306864
Package Type:Retail
Warranty:3 Years
Chipset:Intel B760
CPU Interface:Socket 1700
CPU Support:https://www.msi.com/Motherboard/PRO-B760-P-WIFI-DDR4/support#cpu
RAM Technology:DDR4 (Dual Channel)
RAM Slots:4 x 288-pin
RAM Speeds:Up to DDR4 5333 (O.C.)
Max. Memory Support:128GB
PCI Express 4.0 x16:2
PCI Express 3.0 x1:3
S-ATA 6Gb/s Port(s):4
RAID:Raid 0/1/5/10
M.2 Socket(s):1 x PCIe Gen 4.0 x4
1 x PCIe Gen 4.0 x4/SATA

On-Board LAN:Realtek RTL8125BG 2.5G LAN
Wireless NIC:Wi-Fi 6E
Bluetooth:v5.3
On-Board Audio:Realtek ALC897 Codec
7.1-Channel High Definition Audio

On-Board Video:Intel processor with integrated graphics is required
Back PS/2 Keyboard/Mouse Port:1
Back USB 2.0 Port(s):4
Back USB 3.2 Port(s) Type-A Gen 2:2
Back USB 3.2 Port(s) Type-C Gen 2:1
Back HDMI Port(s):1
Back DisplayPort(s):1
Back LAN Port(s):1
Back Audio Jack(s):5
Back S/PDIF Output Port(s):1
Back Other Port(s):Wi-Fi / Bluetooth
24-pin ATX Power:1
8-pin ATX Power:2
USB 2.0 Header(s):4
USB 3.2 Header(s) Gen 1:3
Parallel Port Header(s):1
COM Port Header(s):1
TPM Header(s):1
Internal Other Port(s):1 x TBT Connector
2 x Addressable V2 RGB LED Connector
1 x RGB LED Connector

Form Factor:Standard ATX
Product Width:243.84mm
Product Length:304.8mm
Package Width:27cm
Package Length:35cm
Package Height:6.5cm
Gross Weight:1.50Kg
Special Features:Lightning Gen4 Solution: The latest Gen4 PCI-E and M.2 solution with up to 64GB/s bandwidth for maximum transfer speed.
Wi-Fi 6E: The latest wireless solution supports 6GHz spectrum, MU-MIMO and BSS colour technology, delivering speeds up to 2400Mbps.
Extended Heatsink Design: MSI extended PWM heatsink and enhanced circuit design ensures even high-end processors to run in full speed.
M.2 Shield FROZR: Strengthened built-in M.2 thermal solution. Keeps M.2 SSDs safe while preventing throttling, making them run faster.
2.5G Network Solution: Featuring premium 2.5G LAN to deliver better network experience.
EZ Debug LED: Easiest way to troubleshoot.
Frozr AI Cooling: Detect CPU and GPU temperatures and automatically adjust system fan duty to a proper value.
Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility.
Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.

Package Contents:Motherboard
Quick Installation Guide
EZ M.2 Clip
SATA Cable
Wi-Fi Antenna
I/O Shield
