MSI PRO DP10 13M Intel Core i5 1340P Barebone Mini PC SFF PRO DP10 13M I5 1340P BB

"PRO DP10 13M: be Your Window to the World

The MSI PRO DP10 13M is a small yet powerful mini-desktop with an incredibly compact 1.1L design suitable for commercial office work or use as home-theatre/entertainment PC (supports UHD/4K 60Hz display output & quad-monitor setups).

The PRO DP10 13M I5 1340P BB configuration is a barebone system equipped with an Intel 13th Gen Core i5-1340P processor, but does not include required DDR4 memory, storage, or software. Features Intel Wi-Fi 6E & Bluetooth 5.3 connectivity.

The easy-to-upgrade SFF case can house both M.2 & 2.5-inch SSD storage, as well as up to 64 GB of system memory (2 x DDR4 3200MHz SO-DIMMs), and is VESA-mountable for a cleaner desktop.

Thanks to its cooling-optimized layout and low-noise fan, the MSI PRO DP10 13M is not only an energy-efficient computing solution but is also very quiet, running at a whisper-level 28 dBA while in idle mode.

Front & rear I/O include a 2.5Gbps ethernet LAN, Mic-in and Headphones-out combo, Thunderbolt 4, USB 3.2 Gen 2 Type-C and 5 x USB 3.2 Gen 1 Type-A ports. Trusted Platform Module 2.0 (dTPM2.0) technology provides security for storing sensitive information."

Features


MSI recommends Windows 11 Pro for business


Up to Intel� Core� i7-1360P Processor


1.1 liter with 185.5 mm in height


Built-in Thunderbolt 4, which delivers the fastest, most versatile connection to any dock, display, or data device & NAS


Support up to 8K resolution display with Thunderbolt


Support up to 4 Monitors with its complete array of I/O ports


Wi-Fi 6E (Optional) puts more emphasis on transmission security with speeds up to 2.4Gbps


Connect and rapidly transfer data over a network with the high-bandwidth and low-latency 2.5Gbps Ethernet LAN


Get all the performance benefits from USB 3.2 Gen 2 Type-C connector


Easy to access and upgrade components to keep the system up to date with the latest hardware


MSI Cloud Center app brings you a private cloud and helps backup files of your mobile devices (Android & iOS)


MSI Center app easily adjusts system modes and resources for various scenarios and needs


TPM design secures your confidential data with encryption keys


Supports standard VESA-mount



Processor


Processor lithography

10 nm


Processor cache

18 MB


Efficient-core boost frequency

3.4 GHz


Performance cores

4


Efficient cores

8


Processor family

Intel� Core� i5


Performance-core boost frequency

4.6 GHz


Processor boost frequency

4.6 GHz


Processor generation

13th gen Intel� Core� i5


Built-in processor

Yes


Processor frequency

4.6 GHz


Processor model

i5-1340P


Processor threads

16


Processor manufacturer

Intel


Processor cores

12



Memory


ECC

No


Number of memory slots

2


Maximum internal memory

64 GB


Memory slots type

SO-DIMM


Supported memory clock speeds

2666,3200 MHz


Memory channels

Dual-channel



Other features


Country of origin

China


Warranty period

2 year(s)



Ports & interfaces


DisplayPort version

1.4


DisplayPorts quantity

1


HDMI ports quantity

1


Thunderbolt 4 ports quantity

1


USB 3?2 Gen 1 (3?1 Gen 1) Type-A ports quantity

5


USB 3?2 Gen 2 (3?1 Gen 2) Type-C ports quantity

1


Microphone in

No


VGA (D-Sub) ports quantity

1


Ethernet LAN (RJ-45) ports

1


HDMI version

2.0b


DVI port

No


DC-in jack

Yes


Combo headphone/mic port

Yes



Graphics


On-board graphics card

Yes


On-board graphics card model

Intel� Iris� Graphics


Graphics card family

Intel



Design


Chassis type

1.1L sized PC


VESA mounting

Yes


Cooling type

Active


Product colour

Black


Panel mounting interface

75 x 75 mm


Product type

Mini PC barebone



Storage


Supported storage drive types

HDD & SSD


NVMe

Yes


Storage drive sizes supported

2.5,M.2


SSD form factor

2.5"


Number of storage drives supported

3


Storage drive interface

M.2, Serial ATA III



Weight & dimensions


Package height

301 mm


Package depth

102 mm


Package width

249 mm


Package weight

2.1 kg


Height

179 mm


Width

178.8 mm


Depth

34.5 mm


Weight

1.1 kg



Packaging content


Quick start guide

Yes


Keyboard included

No


Power cord included

Yes


Drivers included

Yes


AC adapter included

Yes


Display included

No


Mouse included

No



Network


LAN controller

Realtek RTL8125-BG, Realtek RTL8125-CG


Bluetooth

Yes


Top Wi-Fi standard

Wi-Fi 6E (802.11ax)


Wi-Fi

Yes


Ethernet LAN

Yes


WLAN controller model

Intel Wi-Fi 6E AX211


Bluetooth version

5.3



Operational conditions


Storage relative humidity (H-H)

0 - 90


Storage temperature (T-T)

-20 - 60 �C



Audio


Built-in speaker(s)

No



Performance


Motherboard chipset

Intel SoC


Compatible processor series

Intel Core i5 13th Gen


Number of processors supported

1


Motherboard form factor

NUC



Power


Number of power supply units

1


Power supply type

External AC adapter


Power supply

120 W
