Netgear GS324P Unmanaged Gigabit Ethernet 10/100/1000 Black 1U Power over Ethern GS324P-100EUS

The NETGEAR SOHO Ethernet Unmanaged Switches provide easy and affordable network connectivity to small offices and home/offices. They are easy to use, reliable, and rugged with metal enclosures. Power-over-Ethernet (PoE) support is also available for supplying both power and data across a single CAT-5 ethernet cable to devices such as IP security cameras, VoIP phones, wireless access points, etc. With these Plug-and-Play switches, you can quickly and easily expand your network connections to multiple devices, with no configuration required. Available with 5 ports to 48 ports, these switches also support energy saving technologies to help you save power and money.

Features


ETHERNET PORT CONFIGURATION: 24 Gigabit ports


POWER-OVER-ETHERNET: 16 PoE+ ports with 190W total power budget to power wireless AP, IP Cameras, IP Phones and much more


PLUG-AND-PLAY: Simple set up with no software to install or configuration needed


VERSATILE MOUNTING OPTIONS: Supports desktop, or rackmount placement, and includes all the necessary mounting hardware in the box


PoE POWER AUTO-BALANCE AND ALLOCATION - NETGEAR's unique PoE technology automatically balances the PoE power at the most granular level on each port, depending on the device needs


QUIET OPERATION: Ideal for noise-sensitive environments


ENERGY EFFICIENT: Designed to optimize power usage lowering its cost to operate. Compliant with IEEE802.3az Energy Efficient Ethernet mode


BUILT TO LAST: Every NETGEAR Network switch is rigorously tested for reliability, quality, and performance



Design


Number of fans

1 fan(s)


Product colour

Black


Electromagnetic compatibility

CE, FCC 15 A, IC A, RCM, VCCI, KC


Rack mounting

Yes


Housing material

Metal


Form factor

1U


Certification

CB, CE LVD, UL


LED indicators

Activity, Link, PoE, Power, Speed



Weight & dimensions


Height

43 mm


Width

330 mm


Depth

206 mm


Weight

2.44 kg



Logistics data


Harmonized System (HS) code

85176990



Network


Networking standards

IEEE 802.1p, IEEE 802.3at


Auto-negotiation

Yes


10G support

No


Full duplex

Yes


Auto MDI/MDI-X

Yes



Data transmission


Packet buffer memory

0.192 MB


Jumbo frames

10000


Latency (1 Gbps)

4 �s


Packet forwarding rate (1 Gbps)

1448000 pps


MAC address table

8000 entries


Jumbo frames support

Yes


Switching capacity

48 Gbit/s



Power over Ethernet (PoE)


Power over Ethernet plus (PoE+) ports quantity

16


Total Power over Ethernet (PoE) budget

190 W


Power over Ethernet (PoE)

Yes


Power over Ethernet (PoE) power per port

30 W



Operational conditions


Operating temperature (T-T)

0 - 45 �C


Heat dissipation

718.2 BTU/h


Operating relative humidity (H-H)

10 - 90


Storage relative humidity (H-H)

10 - 95


Storage temperature (T-T)

-20 - 70 �C


Operating altitude

0 - 3000 m



Ports & interfaces


Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)


Basic switching RJ-45 Ethernet ports quantity

24



Security


Queue scheduling algorithms

Weighted Round Robin (WRR)



Performance


Mean time between failures (MTBF)

1193574 h



Management features


Quality of Service (QoS) support

Yes


Switch type

Unmanaged



Power


AC input voltage

100 - 240 V


AC input frequency

50 - 60 Hz


Input current

3 A


Power consumption (max)

210 W
