Noctua NH-L9X65 NH-L9X65 CPU-Cooler - 92mm NH-L9X65

The NH-L9x65 is a taller, performance-enhanced version of Noctua�s award-winning NH-L9 low-profile coolers. With 65 instead of 37mm height and four instead of two heatpipes, the NH-L9x65 is more powerful than its smaller siblings yet retains their 95x95mm footprint, which guarantees 100% RAM and PCIe compatibility on Intel based ITX mainboards and makes the cooler more convenient to work with as it doesn�t overhang near-socket connectors. Thanks to the highly optimised NF-A9x14 premium fan that supports fully automatic speed control via PWM, the NH-L9x65 runs remarkably quiet. Topped off with the professional SecuFirm2� multi-socket mounting system for Intel and AMD, Noctua�s renowned NT-H1 thermal compound and 6 years manufacturer�s warranty, the NH-L9x65 fuses everything users have come to expect from Noctua�s larger coolers into a compact premium package for space restricted systems.

Caution: The NH-L9x65 is a highly-compact low-profile quiet cooler designed for use in small form factor cases and HTPC environments. While it provides first rate performance in its class, it is not suitable for overclocking and should be used with care on CPUs with more than 84W TDP (Thermal Design Power). Please consult our TDP guidelines to find out whether the NH-L9x65 is recommended for your CPU.

Logistics data



Harmonized System (HS) code



84733080


Other features



Harmonized System (HS) code



84733080


Heatsink dimensions (W x D x H)



95 x 51 x 95 mm


Package dimensions



Gross Weight (Package, kg)



0.5 kg


Performance



Airflow



57.5 m�/hr


Fan diameter



9.2 cm


Maximum air pressure



2.11 mmH2O


Mean time between failures (MTBF)



150000 Hour


Minimum air pressure



1.06 mmH2O


Noise level (high speed)



23.6 dB


Noise level (low speed)



14.8 dB


Rotational speed (max)



2500 RPM


Rotational speed (min)



600 RPM


Suitable for



Processor


Suitable location



Processor


Supported processor sockets



Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket FM1, Socket FM2, Socket FM2+


Type



Cooler


Power



Voltage



12 V


Product dimensions



Net Weight (Product, kg)



0.2 kg


Product Depth



6.5 cm


Product Height



9.5 cm


Product Width



9.5 cm


Vendor information



Brand Name


Noctua


Warranty



1 Year(s)


Weight & dimensions



Fan dimensions (W x D x H)



92 x 14 x 92 mm


Heatsink dimensions (W x D x H)



95 x 51 x 95 mm


Heatsink weight



340 g
