Opticon 12305 C37. RS232. CCD. Black 12305

The C37 is a durable CCD scanner with a wide optical window. With its aggressive scan engine the C37 operates at a speed of 200 scans per second. Available in black and white, this sleek scanner fits on every desk.

This lightweight and ergonomically shaped device fits comfortably in anyone's hand, making it suitable for all-day scanning applications.

The C37 is available with the most popular interfaces: USB, Keyboard Wedge and RS232. This device is easily programmable to suite your application.

Design



Certification



CE, FCC, VCCI, RoHS


International Protection (IP) code



IP42


Product colour



Black


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 50 °C


Storage temperature (T-T)



-20 - 60 °C


Other features



Dimensions (WxDxH)



53 x 150 x 75 mm


Light source



LED


Package dimensions



Gross Weight (Package, kg)



0.2 kg


Performance



Buzzer



Yes


Certification



CE, FCC, VCCI, RoHS


International Protection (IP) code



IP42


Product colour



Black


Ports & interfaces



Bluetooth



No


Standard interfaces



USB, RS-232


Power



Input voltage



6 V


Product dimensions



Net Weight (Product, kg)



0.1 kg


Scanning



Pitch reading angle



-35 - 35 °


Read rate (max)



200 reads/s


Sensor type



CCD


Tilt reading angle



-20 - 20 °


Wavelength



650 nm


Yaw reading angle



20 - 70 °


Technical details



Harmonized System (HS) code



84716070


Vendor information



Brand Name


Opticon


Homepage



http://www.opticon.com/C37.aspx


Warranty



2 Year(s)
