Planet
Planet ANT-FP14D 2.4GHz 14dBi Flat Panel Dual ANT-FP14D
- UPC:
- 4711605281461
- MPN:
- ANT-FP14D
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
PLANET ANT-FP14D is a 2.4GHz 14dBi Flat Panel Dual Polarization Directional Antenna equipped with two N-Type Female connectors. The ANT-FP14D can increase wireless signal coverage and improve signal strength and quality for the current wireless environment. As the ANT-FP14D can effectively enhance the performance and coverage of the 802.11b/g/n 2.4GHz facilities, it is quite suitable for outdoor wireless LAN applications such as point-to-point connection between the warehouses.
The ANT-FP14D Dual Polarization Directional Antenna can operate in both vertical and horizontal polarization. The dual-polarized antennas are perfectly helpful for 802.11n devices in multithreaded communications. This enables the wireless device to transmit data on one polarization and receive data on the other polarization simultaneously. Obviously, all the networking equipment in the wireless network must be multithreading complaint. It thus brings users the advantage that multithreaded communications can be achieved with use of only one antenna instead of two independent (and opposite polarized) antennas.
Features
Antenna connector type
N-type
Antenna type
Directional antenna
Connector gender
Female
Housing material
Acrylonitrilbutadienstyren
Mounting
Pole
Polarization
Dual polarization
Product colour
White
Survival wind speed
241.4 kmh
Ultraviolet (UV) resistant
Yes
Voltage Standing Wave Ratio (VSWR)
1.5
Waterproof
Yes
Operational conditions
Operating relative humidity (H-H)
0 - 95 %
Operating temperature (T-T)
-40 - 70 �C
Package dimensions
Depth (package,cm)
49.5 cm
Gross Weight (Package, kg)
1.18 kg
Height (package,cm)
33 cm
Width (package,cm)
27 cm
Packaging content
Mounting kit
Yes
Quantity
1
Quantity per pack
1 pc(s)
Performance
Antenna gain level (max)
14 dBi
Frequency band
2.4 ~ 2.5 GHz
Horizontal beam width
30 �
Impedance
50 ?
Networking standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Vertical beam width
30 �
Product dimensions
Net Weight (Product, kg)
0.58 kg
Product Depth
1.5 cm
Product Height
22.8 cm
Product Width
22.8 cm
Vendor information
Brand Name
Planet
Warranty
2 Year(s)
View AllClose
The ANT-FP14D Dual Polarization Directional Antenna can operate in both vertical and horizontal polarization. The dual-polarized antennas are perfectly helpful for 802.11n devices in multithreaded communications. This enables the wireless device to transmit data on one polarization and receive data on the other polarization simultaneously. Obviously, all the networking equipment in the wireless network must be multithreading complaint. It thus brings users the advantage that multithreaded communications can be achieved with use of only one antenna instead of two independent (and opposite polarized) antennas.
Features
Antenna connector type
N-type
Antenna type
Directional antenna
Connector gender
Female
Housing material
Acrylonitrilbutadienstyren
Mounting
Pole
Polarization
Dual polarization
Product colour
White
Survival wind speed
241.4 kmh
Ultraviolet (UV) resistant
Yes
Voltage Standing Wave Ratio (VSWR)
1.5
Waterproof
Yes
Operational conditions
Operating relative humidity (H-H)
0 - 95 %
Operating temperature (T-T)
-40 - 70 �C
Package dimensions
Depth (package,cm)
49.5 cm
Gross Weight (Package, kg)
1.18 kg
Height (package,cm)
33 cm
Width (package,cm)
27 cm
Packaging content
Mounting kit
Yes
Quantity
1
Quantity per pack
1 pc(s)
Performance
Antenna gain level (max)
14 dBi
Frequency band
2.4 ~ 2.5 GHz
Horizontal beam width
30 �
Impedance
50 ?
Networking standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Vertical beam width
30 �
Product dimensions
Net Weight (Product, kg)
0.58 kg
Product Depth
1.5 cm
Product Height
22.8 cm
Product Width
22.8 cm
Vendor information
Brand Name
Planet
Warranty
2 Year(s)
