Planet HDP-5240PT 720p SIP Multi-unit Video HDP-5240PT
- UPC:
- 4711605282499
- MPN:
- HDP-5240PT
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Security is Ensured with PLANET Video Door Phone
PLANET HDP-5240PT is a SIP Door Phone with PoE feature. It supports H.264 video compression format and delivers excellent picture quality in 720p HD video resolutions at 10~30 frames per second (fps). It also supports HD (High Definition) voice and G.722 codec that relax bandwidth limitation and provide clear communications. It provides the flexibility and control required for high-quality property complex visitor management, property protection, intercom, and message service.
High-quality Audio and Video
With the integrated HD camera and advanced audio system with the echo cancellation function, the intercom provides sharp images and excellent audibility in all conditions. With the HTS-1000P touch screen control pad, you can view video from the intercom camera at any time. This allows you to have a constant overview of what is happening outside the door.
Keyless Control and Convenience
PLANET HDP-5240PT advancements in residential door lock security have been enhanced with secure authentication technology which supports many ways of opening door without a key. The door not only can be open via an RFID card but also a password if it is an electronic door lock. Thus, you can enter your home without having to use a key.
SIP 2.0 Standard Compliance
The HDP-5240PT supports Session Initiation Protocol 2.0 (RFC 3261) for easy integration with general voice over IP system. The IP phone is able to broadly interoperate with equipment provided by VoIP infrastructure providers, thus enabling them to provide their customers with better multimedia exchange services.
AEC (Acoustic Echo Cancellation)
Acoustic Echo Cancellation (AEC) technology is adopted in PLANET�s HDP-5240PT Door Phone and Video Phone to enable users to minimize the voice/sound signal distortion shown in the diagram below, thus guaranteeing the best-in-class sound quality.
Finding the Door Phone via Planet Search Tool
PLANET Search Tool is a simple, freely-available application for locating intercoms from the IP family in the network. After searching the network, the application shows the device name, firmware version and IP address of all intercoms found on a chart. This simplifies the administration and installation of intercom systems. Simply run the easy-to-use software to get immediate results.
Camera
Maximum frame rate
30 fps
Maximum image resolution
1280 x 720 Pixels
Megapixel (approx.)
1 MP
Minimum illumination
1 lx
Optical sensor size
1.4 "
Sensor type
CMOS
Viewing angle, horizontal
110 �
Viewing angle, vertical
95 �
Design
International Protection (IP) code
IP65
Product colour
Black, Stainless steel
Network
Cabling technology
10/100Base-T(X)
Ethernet interface type
Fast Ethernet
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10, 100
Networking standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Power over Ethernet (PoE)
Yes
Operational conditions
Operating relative humidity (H-H)
10 - 90 %
Operating temperature (T-T)
-20 - 60 �C
Storage temperature (T-T)
-40 - 70 �C
Package dimensions
Depth (package,cm)
30 cm
Gross Weight (Package, kg)
0.51 kg
Height (package,cm)
20 cm
Width (package,cm)
23 cm
Power
Power consumption (standby)
2.76 Watt
Product dimensions
Net Weight (Product, kg)
0.35 kg
Product Depth
9.3 cm
Product Height
3.5 cm
Product Width
16 cm
Technical details
Built-in microphone
Yes
Built-in speaker(s)
Yes
Certification
CE, FCC
Colour
Yes
Contrast adjustment
Yes
Echo cancellation
Yes
Harmonized System (HS) code
85176920
Maximum number of cameras supported
1
Number of buttons
12 buttons
Number of speakers
1
Ringer volume adjustment
Yes
Speaker power
3 Watt
Speakerphone
Yes
Streaming capability
Yes
Video codecs
H.264
Voice codecs
G.711a, G.711u, G.722, G.723.1, G.726, G.729ab
Wall mountable
Yes
Vendor information
Brand Name
Planet
Warranty
2 Year(s)
