Planet KVM-210-16 16-Port Combo KVM Switch: KVM-210-16

Easily Control Servers with Flexibility

PLANET offers an ideal enterprise 16-port KVM switch solution for company server room or testing facilities. The KVM-210-16 16-port Combo KVM Switch features the patented design of the availability of USB and PS/2 interface connection, user-friendly OSD utility and daisy-chain function. The KVM switch solution frees up more table and rack space for users in addition to saving the cost of multiple keyboards, mice and monitors.


Computer Switching

There are three convenient methods to access any computer connected to the installation:* Port select button
* Hotkeys on keyboard
* OSD (on screen display)


Flexible LED Display

You could check the computer status on the front LED of the KVM-210-16. "Red" indicates that a computer is connected to the corresponding port and "Green" indicates that the computer connected to the corresponding port has focus.


Two Level Password Security Protection

Two level password security only authorizes up to one user and an administrator with a separate profile for each user.


Easy to Install

Simply plug cables into their appropriate ports. There is no software to configure, and no incompatible problems. It works on multiple operating platforms like Windows, Linux, Mac, Sun, etc.


Powerful Mouse/Keyboard Support

In the present computer applications, a mouse has become an indispensable device. The KVM-210-16 fully supports all models of PS/2 mice on the market. The KVM also supports the PS/2 keyboard port of code set 1/2/3 and further allows you to use the KVM for all kinds of servers, computers or their combination.

Design



Housing material



Metal


LED indicators



Y, Yes


Product colour



Black


Push button



Yes


Rack capacity



1U


Rack mounting



Yes


Display



Built-in display



No


Operational conditions



Operating relative humidity (H-H)



0 - 90 %


Operating temperature (T-T)



-10 - 50 �C


Package dimensions



Depth (package,cm)



48.5 cm


Gross Weight (Package, kg)



3.15 kg


Height (package,cm)



45 cm


Width (package,cm)



34 cm


Performance



HD type



Not supported


Ports & interfaces



Console ports



PS/2, USB A, VGA (D-Sub)


Keyboard port type



USB, PS/2


Mouse port type



USB, PS/2


Number of computers controlled



16


Video port type



VGA


Power



Power source



DC


Product dimensions



Net Weight (Product, kg)



2.11 kg


Product Depth



15.5 cm


Product Height



4.4 cm


Product Width



43.2 cm


Vendor information



Brand Name


Planet


Warranty



2 Year(s)
