RAM Mounts RAM-101B2-TAB23U RAM� Dashboard Mount with RAM-101B2-TAB23U

The RAM� Tab-Tite� bundle is a rugged mount including the RAM� Tab-Tite�, RAM� Universal Double Ball Mount with Two Round Plates, and RAM� Backing Plate Adapter. The RAM� Tab-Tite� spring loaded, quick release holder offers a secure fit with easy access to the mounted tablet. The spring loaded design makes it easy to insert and remove your tablet, along with keeping it secure in mobile applications. The custom end cups are designed to optimize the functionality of your tablet, enabling access to all ports and tablet functions. The RAM-101U-B consists of a short double socket arm and two 2.5" diameter round bases with the universal AMPS hole pattern. Designed into the mount is a 1.5" diameter patented rubber ball and socket system with adjustment points at both socket ends of the arm. Rubber ball and socket technology allows for almost infinite adjustment and perfect viewing angles. The included 2.10" x 2.60" steel backing plate with #8-32 threaded holes attaches to a variety of RAM� Mounts ball bases.

Design



Device mount type



Screw mount


Material



Aluminium, Composite, Steel


Mobile device type



Tablet/UMPC


Orientation



Vertical


Product colour



Black


Proper use



Car/Indoor


Type



Passive holder


Ergonomics



Adjustable width



Yes


Height adjustment



Yes


Maximum device depth



1.5 cm


Maximum device height



27.7 cm


Maximum device width



13.4 cm


Maximum screen size



8 "


Minimum device depth



3 mm


Minimum device height



21.1 cm


Minimum device width



11.2 cm


Minimum screen size



7 "


Product dimensions



Net Weight (Product, kg)



0.898 kg


Vendor information



Brand Name


RAM Mounts


Warranty



99 Year(s)
