Raritan MCD-108 MasterConsole Digital CAT5 KVM MCD-108

Raritan�s MasterConsole Digital KVM switch (MCD) is ideal for small to midsized businesses (SMB) who need to have a centralized point of access to multiple servers without the expense and clutter of a dedicated keyboard, mouse, and monitor for each computer or server. The MCD supports the highest HD video resolution of up to 1920x1080 via standard Category 5/6/6e cabling. The multi-format video interface supports both Analog � VGA and Digital � DVI, HDMI and DisplayPort. Stereo audio is also supported by using VGA combo cables or MCD�s HDMI adaptors.

MasterConsole Digital KVM is available as a single-user switch and a dual-user switch to control multiple servers. It features KVM ports for 8, 16, or 32 servers and can be cascaded 2 levels to support up to 1024 connections at distances up to 150 feet (45 meters). Connecting to a computer is made easier with the use of standard Category 5/6/6e cables. MCD provides a friendly OSD (On-Screen Display) interface and hotkeys for quick and easy access connected computers. It is ideal for performing system maintenance, administration, running applications, and troubleshooting.

Design



Product colour



Black


Rack capacity



1U


Rack mounting



Yes


Display



Built-in display



No


Logistics data



Harmonized System (HS) code



85176200


Network



Ethernet LAN



Yes


Ethernet LAN (RJ-45) ports



8


Package dimensions



Gross Weight (Package, kg)



3.78 kg


Performance



HD type



WUXGA


Maximum resolution



1920 x 1200 Pixels


Ports & interfaces



Audio connections



Yes


Keyboard port type



USB


Mouse port type



USB


Number of computers controlled



8


USB connector type



USB Type-A


Video port type



DVI-D


Power



AC input voltage



100 - 240 V


DC input voltage



12 V


Input current



1.5 A


Power consumption (typical)



65 Watt


Power source



AC


Product dimensions



Net Weight (Product, kg)



3.53 kg


Product Depth



53.5 cm


Product Height



13 cm


Product Width



30 cm


Vendor information



Brand Name


Raritan


Warranty



2 Year(s)
