StarTech.com 135B-USBC-HDMI212M StarTech.com 6ft 2m USB-C 135B-USBC-HDMI212M

Connect a DP Alt Mode enabled USB-C source to an HDMI monitor, located up to 6.6ft (2m) away, with support for HDR video and resolutions up to 8K 60HzConnect an 8K 60Hz or a 4K 144Hz HDMI display to a DP Alt Mode-enabled USB Type-C source, at a distance of up to 6.6ft (2m), using this USB-C to HDMI Adapter Cable.High-Resolution HDR VideoThis USB-C to HDMI Cable enables resolutions of up to 8K 60Hz and is HDMI 2.1 FRL complaint. It supports HDR10, HDCP 1.x/2.2/2.3, and DSC 1.1/1.2a. The adapter cable supports 7.1 channel audio with Dolby Atmos and DTS:X.Hardware PlatformSingle MonitorDisplayPort Alt ModeIntel 11 th Gen & Later Processors8K 60Hz or 4K 144Hz*DisplayPort 1.4Nvidia RTX3000 and AMD RX6000 or later8K 60Hz or 4K 144HzDisplayPort 1.4Intel 10th Gen & Earlier4K 60HzDisplayPort 1.4Apple M1/M2 + Pro & Max4K 60Hz**DisplayPort 1.4*DSC support required to reach maximum resolution capabilities on Intel 11th Gen or later**Apple MacBook's with M1/M2 silicon can only support up to 4K 60Hz through HDMIUniversal CompatibilityThe USB-C to HDMI Converter Cable is compatible with laptops and devices from various brands such as Dell, HP, Lenovo, Microsoft, and more. It works with all hardware platforms and any operating system. The USB Type-C to HDMI Cable requires no drivers or software and works with USB-C DP Alt Mode, USB4, Thunderbolt 3, and Thunderbolt 4 laptops and devices.Note: Apple M1/M2 devices, including MacBook Pro, can only support up to 4K 60Hz over USB-C DP Alt Mode and cannot achieve 8K 60Hz.Thoughtfully DesignedCombining a video adapter and cable minimizes potential points of failure and signal loss. Adaptive receiver equalization optimizes the input signal and amplifies the output signal to ensure compatibility with high-resolution monitors. The cable is equipped with cage shielding to prevent Electromagnetic Interference (EMI).The StarTech.com Advantage

Features



Cable length



2 m


Cable type



Round cable


Chipset



VMM7100


Connector 1



USB Type-C


Connector 1 form factor



Straight


Connector 1 gender



Male


Connector 2



HDMI Type A (Standard)


Connector 2 form factor



Straight


Connector 2 gender



Male


Connector housing material



Plastic


Converter type



Active video converter


Dolby technologies



DTS:X, Dolby Atmos


HDCP



Yes


HDCP version



1.4/2.2/2.3


HDMI version



2.1


High Dynamic Range (HDR) supported



Yes


High Dynamic Range (HDR) technology



High Dynamic Range 10 (HDR10)


Jacket material



Polyvinyl chloride (PVC)


Maximum refresh rate



144 Hz


Maximum resolution



7680 x 4320 Pixels


Plug and Play



Yes


Product colour



Grey


Refresh rate at maximum resolution



60 Hz


Supported audio channels



7.1


Supported graphics resolutions



3840 x 2160, 2560 x 1440, 5120 x 1440, 7680 x 4320, 1920 x 1080 (HD 1080)


USB Type-C DisplayPort Alternate Mode



Yes


Logistics data



Master (outer) case height



42 cm


Master (outer) case length



43.5 cm


Master (outer) case width



41.5 cm


Products per master (outer) case



120 pc(s)


Operational conditions



Operating relative humidity (H-H)



0 - 80 %


Operating temperature (T-T)



0 - 40 �C


Storage temperature (T-T)



0 - 75 �C


Package dimensions



Depth (package,cm)



22 cm


Gross Weight (Package, kg)



0.03 kg


Height (package,cm)



1.2 cm


Width (package,cm)



20 cm


Packaging data



Quantity per pack



1 pc(s)


Product dimensions



Net Weight (Product, kg)



0.02 kg


Sustainability



Sustainability certificates



RoHS, CE


Sustainability compliance



Yes


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)


Weight & dimensions



Cable diameter



4.8 mm
